C-1
Cisco Nexus 3000 Series Hardware Installation Guide
OL-25338-04
APPENDIX
C
Cable and Connector Specifications
This appendix provides cable and port specifications for all of the Cisco Nexus 3000 Series switches.
This appendix includes the following sections:
• Console Port, page C-2
• Supported Power Cords and Plugs, page C-2
• Jumper Power Cord, page C-8
Console Cable
The console cable has a RJ-45, RS-232 connector on one end and a DB9 connector on the other end. See
Figure C-1.
Figure C-1 Console Cable
187491
