Cisco NIM-ES2-8 User Manual

Table 1: Number of Modules Supported on Cisco ISR 4000
CommentsSKU4000 Series ISR s
Need SM-X-NIM-ADPTR54451-X
34431
Need SM-X-NIM-ADPTR54351
Need SM-X-NIM-ADPTR34331
24331
For information about these and other features available in Cisco NIM-ES2-4 and Cisco NIM-ES2-8s, see
the Cisco 4-Port and 8-Port Layer 2 Gigabit EtherSwitch Network Interface Module Configuration Guide at
the following URL:
hhttp://www-author.cisco.com/c/en/us/td/docs/routers/access/interfaces/NIM/software/configuration/guide/4_8PortGENIM.html/
The following modules are available with this release of the hardware:
• NIM-ES2-4—4-ports Layer 2 10/100/1000 Gigabit Ethernet Switch, Network Interface Module form
single-wide factor.
• NIM-ES2-8—8-ports Layer 2 10/100/1000 Gigabit Ethernet Switch, Network Interface Module single-wide
form factor.
• NIM-ES2-8-P with POE support —8-ports Layer 2 10/100/1000 Gigabit Etherne Switch, Network
Interface Module single-wide form factor.
Cisco 4-Port Layer 2 Gigabit EtherSwitch Network Interface Module
The below figure shows the Cisco 4-Port Layer 2 Gigabit EtherSwitch NIM.
Figure 1:
GE33GE01
GE14GE22
Installing the Cisco 4-Port and 8-Port Layer 2 Gigabit EtherSwitch Network Interface Module
2
Installing the Cisco 4-Port and 8-Port Layer 2 Gigabit EtherSwitch Network Interface Module
Cisco 4-Port Layer 2 Gigabit EtherSwitch Network Interface Module
