Figure 61: LTE USB 2.0 Dongle for C1101-4P

DescriptionNumber

Supporting ring1

Magnet2

Extend outward 30mm3

Plug-in direction4

DescriptionNumber

Supporting ring1

Dongle holder with magnet2

Router-C1101-4PLTEPW3

Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router

Install and Upgrade Internal Modules and Field Replaceable Units

Install a Micro-SIM Card into a USB LTE Dongle
