Cisco PIX Security Appliance Hardware Installation Guide
78-15170-03
Chapter 7 PIX 535
Installing a Circuit Board in the PIX 535
Table 7-4 PIX 535 Interface Options
Restricted Interface Options Unrestricted Interface Options
8 GE 9 GE
8 GE + 1 VPN Accelerator 8 GE + 1 FE
7 GE + 1 FE 8 GE + 1 VPN Accelerator
7 GE + 1 FE + 1 VPN Accelerator 7 GE + 2 FE
6 GE + 2 FE 7 GE + 1 FE + 1 VPN Accelerator
6 GE + 2 FE + 1 VPN Accelerator 6 GE + 3 FE
5 GE + 3 FE 6 GE + 2 FE + 1 VPN Accelerator
5 GE + 3 FE + 1 VPN Accelerator 5 GE + 4 FE
4 GE + 4 FE 5 GE + 3 FE + 1 VPN Accelerator
4 GE + 4 FE + 1 VPN Accelerator 5 GE + 1 FE + 1 4-port FE
3 GE + 5 FE 5 GE + 1 FE + 1 4-port FE + 1 VPN Accelerator
3 GE + 5 FE + 1 VPN Accelerator 4 GE + 5 FE
2 GE + 6 FE 4 GE + 4 FE + 1 VPN Accelerator
2 GE + 6 FE + 1 VPN Accelerator 4 GE + 2 FE + 1 4-port FE
2 GE + 2FE + 1 4-port FE 4 GE + 2 FE + 1 4-port FE + 1 VPN Accelerator
2 GE + 2FE + 1 4-port FE + 1 VPN
Accelerator
3 GE + 6 FE
1 GE + 3 FE + 1 4-port FE 3 GE + 5 FE + 1 VPN Accelerator
1 GE + 3 FE + 1 4-port FE + 1 VPN
Accelerator
3 GE + 1 4-port FE + 3 FE
8 FE 3 GE + 5 FE + 1 VPN Accelerator
8 FE + 1 VPN Accelerator 3 GE + 3 FE + 1 4-port FE
4 FE + 1 4-port 3 GE + 3 FE+ 1 4-port FE + 1 VPN Accelerator
4 FE + 1 4-port + 1 VPN Accelerator 2 GE + 2 4-port FE
2 4-port + 1 VPN Accelerator 2 GE + 2 4-port FE + 1 VPN Accelerator
2 GE + 4 FE +1 4-port FE
2 GE + 4 FE + 1 4-port FE + + 1 VPN Accelerator
2 GE + 7 FE
2 GE + 6 FE + 1 VPN Accelerator
9 FE
8 FE + 1 VPN Accelerator
2 4-port FE + 2 FE
2 4-port FE + 2 FE + 1 VPN Accelerator
1 4-port FE card + 6 FE
1 4-port FE card + 6 FE + 1 VPN Accelerator
1GE + 1FE + 2 x 4FE cards
