Chapter 3 Installing the Router
Installing the Chassis
Center-Mount Installation
Figure 3-18 through Figure 3-22 show how to install brackets for a center-mounted rack installation.
Figure 3-18 Cisco 3620 Center-Mount Bracket Attachment
Figure 3-19 Cisco 3631 Center-Mount Bracket Attachment—Front Panel Forward (19- or 23-Inch Rack)
Figure 3-20 Cisco 3631 Center-Mount Bracket Attachment—Rear Panel Forward (19- or 23-Inch Rack)
