Cisco Router Cisco 3600 User Manual

1-Port Fast Ethernet and 1-Port or 2-Port Channelized T1/ISDN PRI Network Modules
Cisco Network Modules Hardware Installation Guide
5-2
1-Port Fast Ethernet and 1-Port or 2-Port Channelized
T1/ISDN PRI Network Modules
This section provides information about the following network modules for Cisco 3600
series modular routers.
• 1-port Fast Ethernet 1-port channelized T1/ISDN PRI network module—Cisco product
number NM-1FE1CT1. (See Figure 5-1.)
• 1-port Fast Ethernet 2-port channelized T1/ISDN PRI network module—Cisco product
number NM-1FE2CT1. (See Figure 5-2.)
Figure 5-1 1-Port Fast Ethernet 1-Port Channelized T1 Network Module
Figure 5-2 1-Port Fast Ethernet 2-Port Channelized T1 Network Module
LOOP BACK
EN
FE–PRI
1FE-1CT1
15228
LOCAL ALARM REMOTE ALARM
CARRIER DETECT
CTRLR 0
10/100BaseT
COLL LINK 100Mbps FDX
LOOP BACK
EN
FE-PRI
1FE-2CT1
10976
LOCAL ALARM REMOTE ALARM
CARRIER DETECT
LOOP BACK
CTRLR 1
CTRLR 0
10/100BaseT
LOCAL ALARM REMOTE ALARM
CARRIER DETECT
COLL LINK 100Mbps FDX
