15
Table 4 Dual Link Connectivity
Port Link Side
3/0/0 Link 0 Subscribers
3/1/0 Link 0 Network
3/2/0 Link 10 Subscribers
3/3/0 Link 1 Network
Table 5 Cascade Connectivity
Port on SCE 8000 #1 Connects to this...
3/0/0 Subscriber side network element
3/1/0 Network side network element
3/2/0 (cascade port) port 3/3/0 on SCE8000 #2
3/3/0 (cascade port) port 3/2/0 on SCE8000 #2
This port on SCE8000 #2
Connects to this....
3/0/0 Subscriber side network element
3/1/0 Network side network element
3/2/0 (cascade port) port 3/3/0 on SCE8000 #1
3/3/0 (cascade port) port 3/2/0 on SCE8000 #1
Table 6 Single Link Connectivity Using the Optical Bypass Module
Optical Bypass Port Connects to this...
A Subscriber side network element
B Network side network element
C SCE platform port 3/0/0
D SCE platform port 3/1/0
CTRL Left External Bypass port on SCE 8000-SCM-E module
Table 7 Dual Link Connectivity Using Optical Bypass Modules
Port on Optical Bypass #1 Connects to this...
A Subscriber side network element
B Network side network element
C SCE platform port 3/0/0
D SCE platform port 3/1/0
CTRL Left External Bypass port on SCE8000-SCM-E module.
Port on Optical Bypass #2 Connects to this...
A Subscriber side network element
B Network side network element
C SCE platform port 3/2/0
