22
Warning Cisco SCE 8000 is fully operational (as above) but one of the following
occurred:
• GBE Management port link is down
• Temperature raised above threshold
• Voltage not in required range
• Fans problem
• Power supply issue
• Insufficient space on the disk
Note If the condition that caused the Cisco SCE8000 to be in Warning
state is resolved (for example, link is up) the Cisco SCE8000 reverts
to Operational state.
Flashing amber
Failure After bootup, system is in Failure state due to one of the following
conditions:
• Power-on test failure
• Three abnormal reboots in less than 30 minutes
• Platform configured to enter Failure mode consequent to
failure-induced reboot (this is configurable using CLI command)
• Severe system health problem, such as extensive overheating or voltage
out of correct operating range
Note Depending on the cause of failure, the management interface and the
platform configuration may or may not be active or available.
Red
Table 9 Power Supply LEDs
LED Label Color State Function
INPUT OK Green On The input voltage is present and within the required range
— Off The input voltage is not present or not within the required range.
OUTPUT FAIL Green On The output voltage is not within the required range.
— Off The output voltage is in the required range.
FAN OK Green On Power supply internal fan is operational.
— Off Power supply internal fan is not operational.
Power (front panel) Green Steady Installed power supplies are functioning normally.
Amber Steady One of the power supply units is disconnected or malfunctioning.
— Off No power.
Table 10 Fan Assembly LED
LED Label Color State Function
FAN STATUS Green On All fans are operational.
— Off One or more of the individual fans are not operational.
Table 8 Cisco SCE 8000 Operational States (continued)
Cisco SCE8000
Operational Status Description Status LED State
