7 300 Series Managed Switches
S
TEP 3 Configure the utility with the following parameters:
• 115200 bits per second
• 8 data bits
• no parity
• 1 stop bit
• no flow control
STEP 4 Enter a user name and password. User names and passwords are
both case sensitive and alpha-numeric. The default username is
cisco, and the default password is cisco.
STEP 5 If this is the first time that you have logged on with the default
username and password, the
Change User Password Page opens.
Select Edit, enter a new administrator password and then select
Execute.
CAUTION Make sure that any configuration changes made are saved
before exiting.
You are now ready to configure the switch. Refer to the
Cisco Small
Business Managed Switch Administration Guide
for further information.
Next Steps
• If you are not using DHCP on your network, set the connection
type on the managed switch to Static and change the static IP
address and subnet mask to match your network topology.
• Save your settings
• Return your computer to its original settings
These tasks can be accomplished by using the procedures in the Cisco
Small Business Managed Switch Administration Guide.

Cisco SG 300-10 Specifications

General

Model	SG 300-10
Ports	10
Port Type	Gigabit Ethernet
Form Factor	Desktop
Layer	Layer 3
PoE	No
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Management	Managed
MAC Address Table Size	8000 entries
VLANs	256
Quality of Service (QoS)	Supported
Security Features	802.1X
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Jumbo Frame Support	Yes (up to 9216 bytes)
Dimensions (W x D x H)	279.4 x 170.18 x 44.45 mm
