Cisco SRW2016 User Manual

Chapter 5
Advanced Configuration
54
WebView Switches
Base Table
Management Station Displays the management station
IP address for which the basic SNMP community is
defined.
Community String Displays the password used to
authenticate the management station to the device.
Access Mode Displays the access rights of the
community.
View Name Displays the user-defined SNMP view.
Advanced Table
Management Station Displays the management station
IP address for which the basic SNMP community is
defined.
Community String Displays the password used to
authenticate the management station to the device.
Group Name Displays advanced SNMP communities
group name.
SNMP > Notification Filter
The Notification Filter screen permits filtering traps based
on OIDs (Object Identifiers). Each OID is linked to a device
feature or a feature aspect. The Notification Filter screen
also allows network managers to filter notifications.
SNMP > Notification Filter
Filter Name Contains a list of user-defined notification
filters.
New Object Identifier Subtree Displays the OID for
which notifications are sent or blocked. If a filter is
attached to an OID, traps or informs are generated and
sent to the trap recipients. Object IDs are selected from
either the Select from List or the Object ID List. There are
two configuration options:
Select from List Select the OID from the list provided.
Object ID Enter an OID not offered in the Select from List
option.
Filter Type Indicates whether informs or traps are sent
regarding the OID to the trap recipients.
Excluded • Restricts sending OID traps or informs.
Included • Sends OID traps or informs.
Use the Add to List button to add the Notification Filter
configuration to the Notification Filter Table at the bottom
of the screen.
