Cisco SX350 Series User Manual

Smartport
Auto Smartport
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 180
10
NOTE If only the IP Phone and Host bits are set, then the Smartport type is ip_phone_desktop.
Multiple Devices Attached to the Port
The device derives the Smartport type of a connected device via the capabilities the device
advertises in its CDP and/or LLDP packets.
VoIP Phone 0x80 ip_phone
Remotely-Managed Device 0x100 Ignore
CAST Phone Port 0x200 Ignore
Two-Port MAC Relay 0x400 Ignore
LLDP Capabilities Mapping to Smartport Type
Capability Name LLDP Bit Smartport Type
Other 1 Ignore
Repeater IETF RFC 2108 2 Ignore
MAC Bridge IEEE Std. 802.1D 3 Switch
WLAN Access Point IEEE Std. 802.11 MIB 4 Wireless Access Point
Router IETF RFC 1812 5 Router
Telephone IETF RFC 4293 6 ip_phone
DOCSIS cable device IETF RFC 4639 and
IETF RFC 4546
7 Ignore
Station Only IETF RFC 4293 8 Host
C-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
9 Switch
S-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
10 Switch
Two-port MAC Relay (TPMR) IEEE Std.
802.1Q
11 Ignore
Reserved 12-16 Ignore
CDP Capabilities Mapping to Smartport Type (Continued)
Capability Name CDP Bit Smartport Type
