Cisco SX350 Series User Manual

IP Configuration
Policy-Based Routing
311 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
15
Route Map Binding
All packets coming in on an interface that is bound to a route map and match a route map rule
are routed to the next hop defined in the rule.
To bind an interface to a route map:
STEP 1 Click IP Configuration > Policy Based Routing > Route Map Binding.
STEP 2 Click Add and enter the parameters:
• Interface—Select an interface (with an ip address).
• Bound IPv4 Route Map—Select an IPv4 route map to bind to the interface.
• Bound IPv6 Route Map—Select an IPv6 route map to bind to the interface.
STEP 3 Click Apply. The Running Configuration file is updated.
Policy-Based Routes
To view the route maps that defined:
STEP 1 Click IP Configuration > Policy Based Routing > Policy Based Routes.
STEP 2 Previously-defined route maps are displayed:
• Interface Name—Interface on which route map is bound.
• Route Map Name—Name of route map.
• Route Map Status—Status of interface:
- Active—Interface is up.
- Interface Down—Interface is down.
• ACL Name—ACL associated with route map.
• Next Hop—Where packets matching route map will be routed.
• Next Hop Status—Reachability of next hop:
- Active—The next hop IP address is reachable.
- Unreachable—The status is not active due to the fact that the next hop IP address is
not reachable.
