Cisco TelePresence IX5000 Installation Guide

Installing the Lower and Upper Display Frames
Page 10
© 2015 Cisco Systems, Inc. All rights reserved.
4
Set the frame position from the rear wall. The distance should be a minimum of 150mm (6 inches) from
the back of the frame to the wall. Measure two positions (left side and right side of the center frame) to
ensure that the frame is parallel to the rear wall.
Minimum 6”
(150 mm)
Rear Wall
