Camera guide
Connect Precision 60 to SX80 Codec
• Connect the video cable to one of the codec’s camera inputs
(HDMI). We recommend using the 1st camera input for the
main camera.
• Connect Ethernet to the codec’s 2nd or 3rd Ethernet port.
• Connect to power.
Power
(100-240 V
AC
, 50/60 Hz)
Power
adapter
Always use the provided power cable
and adapter (12 V
DC
, minimum 3 A).
RJ45 HDMI
