Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
BASE SERVER STANDARD CAPABILITIES and FEATURES
7
Video The Emulex Pilot 3 Integrated Baseboard Management Controller provides
video:
■ Matrox G200e video controller
■ Integrated 2D graphics core with hardware acceleration
■ Supports all display resolutions up to 1920 x 1200 x 16 bpp resolution at
60 Hz
■ 24-bit color depth for all resolutions less than 1600x1200
■ Up to 256 MB video memory
Interfaces ■ Rear panel
• One DB9 serial port connector
• Four USB 2.0 port connectors
• One DB15 VGA connector
• One 10/100/1000 Ethernet management port
• Two 1 GbE Ethernet LOM ports
■ Front panel
•Two USB 2.0 ports
Front Panel ■ A front panel controller provides status indications and control buttons
Power subsystem One 450 W power supply or one 650 W power supply, depending on server
configuration and loading. Prior to making a power supply selection, the UCS
Power Calculator should be run to determine the right size power supply for
your server configuration. A fully configured C22 M3 server may require the
650 W power supply. The UCS Power Calculator can be found at the following
link:
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Fans Chassis:
■ Five fans for front-to-rear cooling. N + 1 redundant.
Power supply:
■ The power supply is equipped with a fan.
Integrated management
processor
Cisco Integrated Management Controller (CIMC).
Depending on your CIMC settings, the CIMC can be accessed through the 1-Gb
Ethernet dedicated management port, the 1-Gb Ethernet LOM ports, or a
Cisco 1225 virtual interface card.
Notes . . .
1. NCSI = network communications services interface protocol. The slot stays active when the server is in standby
power state.
2. CNIC = Cisco network interface card.
Capability/Feature Description
