Cisco UCS C22 M3 User Manual

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
56
SUPPLEMENTAL MATERIAL
Rear Panel
Figure 12 shows the rear panel LEDs.
Figure 12 Front Panel LEDs
Blinking (green) Activity on any of the LOM ports
Hard Drive Fault Off The hard drive is operating properly
On (amber) The hard drive has failed
Blinking (amber) The hard drive is rebuilding
Hard Drive Activity Off There is no hard drive in the hard drive sled (no access,
no fault)
On (green) The hard drive is ready
Blinking (green) The hard drive is reading or writing data
1 Power supply fault LED 5 10/100/1000 Ethernet dedicated
management link status LED
2 Power supply AC OK LED 6 10/100/1000 Ethernet dedicated
management link speed LED
3 1-Gb Ethernet link speed LED 7 Rear Identification button/LED
4 1-Gb Ethernet link status LED -
Table 27 Front Panel LEDs (continued)
LED LED State Meaning
285202
PSU 1
PCIe 2 PCIe 1
1
2
3
4
5 7
6
