Getting to Know the Cisco UCS C220 M5SX Server
The components of the Cisco UCS C220 M5SX Server front and rear panels (see the illustration
inside the back cover of this document) are highlighted in Table 1.
Table 1: Components of the Cisco UCS C220 M5SX Server Front and Rear Panels
Front Panel
1
Drive bays 1 – 10 support SAS/SATA hard disk drives (HDDs) and solid
state drives (SSDs)
2
UCSC-220-M5SX: Drive bays 1 and 2 support NVMe PCIe SSDs
3
Power button/power status LED
4
Unit identification button/LED
5
System status LED
6
Power supply status LED
7
Fan status LED
8
Network link activity LED
9
Temperature status LED
10
Pull-out asset tag
11
KVM connector (used with KVM cable that provides one DB-15 VGA,
one DB-9 serial, and two USB connectors)
Rear Panel
1
Modular LAN-on-motherboard (mLOM) card bay (x16 PCIe lane)
2
USB 3.0 ports (two)
3
Dual 1-Gb/10-Gb Ethernet ports (LAN1 and LAN2)
4
VGA video port (DB-15 connector)
5
1-Gb Ethernet dedicated management port
6
Serial port (RJ-45 connector)
7
Rear unit identification button/LED
8
Power supplies (two, redundant as 1+1)
9
PCIe riser 2/slot 2 (x16 lane)
10
PCIe riser 1/slot 1 (x16 lane)
11
Threaded holes for dual-hole grounding lug
English

Cisco UCS C220 M5SX Specifications

General

Brand	Cisco
Model	UCS C220 M5SX
Category	Server
Language	English
