Cisco WAP321 Manual

default static IP address after 60 seconds.
Step 3. Login with the default credentials.The default username is cisco, and the
default password is cisco.
Factory Default Reset by Web Configuration Utility
Step 1. Log in to the web configuration utility and choose Administration > Reboot.
The Reboot page opens:
Step 2. Click Reboot To Factory Default to reboot the access point and return the
device to factory default settings. Once rebooted to factory default, all saved
configurations will be lost.
Step 3. The Confirm window appears. Click OK to continue with the reboot to factory
default settings.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
