Checking TCAM Usage

Supervisor IV and V Have Larger TCAMs

• Input feature TCAM is used for security based features: PACL; RACL; DHCP

Snooping; Dynamic ARP Inspection; IP Source Guard

• Output feature TCAM is used for outbound RACLs and PACLs; DHCP

Snooping

r3_4507R_S4#sh platform hardware acl statistics utilization (truncated output from

Supervisor II-Plus)

Software Usage Statistics

Input FeatureCam

Used (%) Free (%) Total

-------------- -------------- ------

PortAndVlan Entries 0 ( 0.0) 1024 (100.0) 1024

PortAndVlan Masks 0 ( 0.0) 128 (100.0) 128

PortOrVlan Entries 231 ( 22.5) 793 ( 77.4) 1024

PortOrVlan Masks 128 (100.0) 0 ( 0.0) 128

Output FeatureCam

PortAndVlan Entries 0 ( 0.0) 1024 (100.0) 1024

PortAndVlan Masks 0 ( 0.0) 128 (100.0) 1

PortOrVlan Entries 11 ( 1.0) 1013 ( 98.9) 1024

PortOrVlan Masks 11 ( 8.5) 117 ( 91.4) 128

Apr 22 09:25:13.626 PDT: %C4K_HWACLMAN-4-ACLHWPROGERR: Input Security: 199 - hardware TCAM limit, some

packet processing will be software switched.

Apr 22 09:25:13.626 PDT: %C4K_HWACLMAN-4-ACLHWPROGERRREASON: Input Security: 199 - out of hardware TCAM

entries.

909090

RST-3508

9805_05_2004_c2

Security ACL Feature TCAM

• Be careful when using L4 ops collapse contiguous

ranges into a single ACE if possible or use eq

operator

• Check TCAM usage as ACLs being added

• Consider a Supervisor IV or V with larger TCAM

space than Supervisor II-Plus

• Mask allocation optimization is in latest IOS

release, 12.2.20 EW
