Supervisor Redundancy
cat4507R#sh module
Chassis Type : WS-C4507R
Power consumed by backplane : 40 Watts
Mod Ports Card Type Model Serial No.
---+-----+--------------------------------------+------------------+-----------
1 2 1000BaseX (GBIC) Supervisor(active) WS-X4013+ JAB071904FP
2 2 1000BaseX (GBIC) Supervisor(standby) WS-X4013+ JAB071904FD
3 48 10/100BaseTX (RJ45)V, Cisco/IEEE WS-X4248-RJ45V JAB074005BE
M MAC addresses Hw Fw Sw Status
--+--------------------------------+---+------------+----------------+---------
1 0009.e845.6300 to 0009.e845.6301 0.3 12.1(20r)EW 12.2(18)EW, EARL Ok
2 0009.e845.6302 to 0009.e845.6303 0.3 12.1(19r)EW 12.2(18)EW, Ok
3 0005.9a80.3c00 to 0005.9a80.3c2f 0.9 Ok
System Failures:
----------------
Power Supply: bad/off (see 'show power')
181818
© 2004 Cisco Systems, Inc. All rights reserved.
RST-3508
9805_05_2004_c2
Supervisor Redundancy
cat4507R#sh mod
Chassis Type : WS-C4507R
Power consumed by backplane : 40 Watts
Mod Ports Card Type Model Serial No.
---+-----+--------------------------------------+------------------+-----------
1 2 1000BaseX (GBIC) Supervisor(active) WS-X4013+ JAB071904FP
2 Standby Supervisor
3 48 10/100BaseTX (RJ45)V, Cisco/IEEE WS-X4248-RJ45V JAB074005BE
M MAC addresses Hw Fw Sw Status
--+--------------------------------+---+------------+----------------+---------
1 0009.e845.6300 to 0009.e845.6301 0.3 12.1(20r)EW 12.2(18)EW, EARL Ok
2 Unknown Unknown Unknown Other
3 0005.9a80.3c00 to 0005.9a80.3c2f 0.9 Ok
System Failures:
----------------
Power Supply: bad/off (see 'show power')
