CITIZEN Android Label Print SDK — Programming Manual
71
2.3.8 drawMaxiCode method
Syntax
int drawMaxiCode (String[] data, int rotation, int x, int y)
Parameters
Parameter
[IN/OUT]
Description
Setting range
data
[IN]
String data
ASCII code character string array
rotation
[IN]
Direction of rotation
CLS_RT_NORMAL: No rotation
CLS_RT_RIGHT90: Rotate CW 90
CLS_RT_ROTATE180: Rotate CW 180
CLS_RT_LEFT90: Rotate CCW 90
x
[IN]
X-coordinate
0000-9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Y-coordinate
Description
Draws the UPS MaxiCode barcode with specifying options such as rotation and coordinates.
The following information are required in the data parameter in order as below:
1) 5-digit - Zip code
2) 4-digit -+4 Zip code
3) 3-digit – Country Code
4) 3-digit - Class of Service
5) Up to 84 digits other information
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
String[] data = new String[] {"90501", "6282", "840", "001", "1Z00004951"};
design.drawMaxiCode(data, LabelConst.CLS_RT_NORMAL, 100, 0);

Citizen CL-S631 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum media length	812.8 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	270 mm
Weight	4500 g
