—33—
Set the partition to the width of the paper roll you are loading.
The partition is set at the factory to the position shown below.
For 3-inch type: 80-mm wide paper roll
For 2-inch type: 58-mm wide paper roll, 60-mm wide paper roll
(2-sheet partition installed.)
1. Turn off the power.
2. Press up on the cover open button to open the paper cover.
3. Press in the position shown by the arrow and set the partition in a slot that matches
the width of the paper roll you are using. However, to use an 83-mm wide paper roll,
remove the partition. Or, when you are using a 60-mm wide paper roll with the 2-
inch type, remove the partition installed for 58-mm.
4. Refer to “5.3 Manual Setting of Memory Switches” to change the paper width
settings.
3.8 Partition for Paper Roll
Make sure the partition is not slanted when setting it for 58-mm or 60-mm paper rolls.
*1: 2-inch type (58/60 mm)
*2: 3-inch type (80/83 mm)
