Measuring altitude
How to read altitude indication (continued)
1 000 ft hand indication
Indication range: ‒1 000 ft to 9 000 ft
The hand points “0” when measured altitude
is 0 ft or higher and lower than 1 000 ft.
On the example in the left, the measured
altitude is indicated as 2 000 ft level.
When measured altitude is lower than 0 ft
+
-
x 10000 ft.
