Citrix ADC MPX
Health Attribute (shell) Health Attribute (CLI) Recommended Range
Fan 5 System Fan 2 Speed (RPM) 1260–18060
Fan 6 Fan 0 Speed (RPM) 1260–18060
12V +12.0 V Supply Voltage 10.704–13.812
5VCC +5.0 V Supply Voltage 4.466–5.737
3.3VCC Main 3.3 V Supply Voltage 2.885–3.690
VBAT Battery Voltage (Volts) 2.591–3.464
5VSB 5V Standby Voltage (Volts) 4.496–5.378
3.3VSB Standby 3.3 V Supply Voltage 2.954–3.552
1.8V PCH Voltage 2 (Volts) 1.618–1.943
PVNN PCH ‑ nl ‑ 0.892–1.072
1.05V PCH
‑ nl ‑
0.915–1.176
2.5V BMC ‑ nl ‑ 2.177–2.804
1.8V BMC ‑ nl ‑ 1.620–1.944
1.2V BMC ‑ nl ‑ 1.074–1.290
1.0V BMC ‑ nl ‑ 0.892–1.072
VcpuVRM ‑ nl ‑ 1.616–1.944
Vcpu CPU 0 Core Voltage (Volts) 0.931–1.195
VDimmABCD (Volts) Voltage 0 (Volts) 1.096–1.344
VDimmEFGH (Volts) Voltage 1 (Volts) 1.096–1.344
PS1 Status Power supply 1 status ‑ na ‑
PS2 Status Power supply 2 status ‑ na ‑
Notes
‑nl‑ Parameter not listed in the output of the stat system -detail command.
‑na‑ Not applicable.
Sample output
The following sections list the dierent ways to view the system sensor health attributes. The data is
a sample representation only. The output from your appliance might be dierent. For the acceptable
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 189
