Citrix ADC MPX 5900 User Manual

Citrix ADC MPX
Health
attribute Unit
Lower
Non-
Recoverable
Lower
Critical
Lower
Non-
Critical
Upper
Non-
Critical
Upper
Critical
Upper
Non-
Recoverable
CPU2
Vcore
Volts 0.480 0.512 0.544 1.488 1.520 1.552
VDIMM AB Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
CD
Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM EF Volts 1.104 1.152 1.200 1.648 1.696 1.744
VDIMM
GH
Volts 1.104 1.152 1.200 1.648 1.696 1.744
+1.5 V Volts 1.248 1.296 1.344 1.648 1.696 1.744
3.3 V Volts 2.640 2.784 2.928 3.648 3.792 3.936
+3.3VSB Volts 2.640 2.784 2.928 3.648 3.792 3.936
5 V Volts 4.096 4.288 4.480 5.504 5.696 6.912
12 V Volts 10.176 10.494 10.812 13.250 13.568 13.886
VBAT Volts 2.400 2.544 2.688 3.312 3.456 3.600
Health attributes for MPX 5500/7500/9700/9700 10G platforms
The following tables list the health attributes and their recommended value ranges.
Health
attributes/-
Platform
SNMP Alarm
Support
MPX
5500/5600
MPX
7500/9500
MPX
9700/10500/12500/15500
MPX
9700/10500/
12500/15500
10G
CPU 0 core
(Volts)
No 0.97–1.5 1–1.5 1–1.5 1–1.5
CPU 1 core
(Volts)
No 0.97–1.5 1–1.5 1–1.5 1–1.5
Main 3.3 V
Supply (Volts)
Yes 3.2–3.6 3.2–3.54 3.2–3.54 3.2–3.55
Standby 3.3 V
Supply (Volts)
Yes 3.2–3.6 3.2–3.54 3.2–3.54 3.2–3.55
