Citrix ADC MPX 5900 User Manual

Citrix ADC MPX
Health
attributes/-
Platform
SNMP Alarm
Support
MPX
5500/5600
MPX
7500/9500
MPX
9700/10500/12500/15500
MPX
9700/10500/
12500/15500
10G
Internal
Temperature
Yes 19–50
(Celsius),
66.2–122
(Fahrenheit)
19–50
(Celsius),
66.2–122
(Fahrenheit)
19–50
(Celsius),
66.2–122
(Fahrenheit)
19–50
(Celsius),
66.2–122
(Fahrenheit)
Power Supply
1 Status
Yes Not
supported
Normal Normal Normal
Power Supply
2 Status
Yes Not
supported
Normal Normal Normal
Health attributes for MPX 5550/8005/115xx/17500/17550 platforms
The following tables list the health attributes and their recommended value ranges.
Health
attributes/-
Platform
SNMP
Alarm
Support
MPX
17500/19500/21500MPX 115xx
MPX
17550/19550/20550/21550MPX8005/8015/8200/8400/8600/8800
MPX
5550/5650/5750
CPU 0 core
(Volts)
No 0.99–1.5 0.95–1.5 0.95–1.5 - NA - - NA -
CPU 1 core
(Volts)
No 0.99–1.5 0.95–1.56 0.95–1.5 - NA - - NA -
Main 3.3 V
Supply
(Volts)
Yes 3.19–3.55 3.19–3.55 3.18–3.55 3.14–3.47 3.14–3.47
Standby 3.3
V Supply
(Volts)
Yes 3.2–3.55 3.1–3.55 3.1–3.55 3.14–3.47 3.14–3.47
+5.0 V
Supply
(Volts)
No 4.8–5.2 4.8–6.24 4.8–5.2 4.75–5.25 4.75–5.25
+12.0 V
Supply
(Volts)
No 11.5–12.35 11.8–12.35 11.5–12.35 11.40–12.60 11.40–12.60
© 1999‒2022 Citrix Systems, Inc. All rights reserved. 196
