150
In the event of a breakdown
Open the bonnet. To access the bulbs, reach
behind the headlamp unit.
Carry out the operations in reverse order to
refit each bulb and check that the bonnet is
closed securely.
Halogen bulbs must be changed with the
headlamps off. Wait a few minutes (risk
of serious burns). Do not touch the bulb
directly with your fingers, use a lint-free
cloth.
It is normal for condensation to form inside
the headlamps. Regular use of the vehicle
eliminates this misting.
The bulbs must be changed with the
ignition off or the battery disconnected.
Wait approximately three minutes after
changing the bulb before reconnecting the
battery.
Check that the lamps are working properly
after each operation.
High-pressure jet wash
When using this type of washer on
stubborn dirt, do not persist on the
headlamps, the lamps and their edges to
avoid damaging their coating and seals.
Front lamps
Dipped beam headlamps/Main
beam headlamps
Type C, H4 – 55W
F
Remove the centre cover by pulling on the
flexible rubber tab.
F Disconnect the electrical connector.
F
Release the retaining tab.
F
Change the bulb taking care to align the
metal part with the grooves on the lamp.
F Reposition the retaining tab.
F
Ensure that the cover is refitted correctly all
around to ensure correct sealing.
Sidelamps
Type A, W5W – 5W
F
Remove the cover by pulling on the flexible
rubber tab.
F Remove the pressure-mounted lamp holder
by pulling the connector.
F Change the bulb.
F
Ensure that the cover is refitted correctly all
around to ensure correct sealing.
Direction indicators
Type B, PY21W – 21W (amber)
F Remove the cover by pulling on the flexible
rubber tab.
F Turn the bulb holder a quarter turn
anticlockwise.
1. Dipped beam headlamps.
2. Sidelamps
3. Direction indicators.
