181
BE4/5 GEARBOX SPECIFICATION
Engines : 6FZ - RFN - RLZ - RHY
CLUTCH
GEARBOX
DRIVESHAFTS
B2CP3CVD B2CP3CWC B2CP3CXC
Adjustments.
WARNING : Control cables should be adjusted each time the gearbox is
removed or cables changed.
WARNING : Do not use oil to detach the ball-joints.
To release the ball-joint, press at the centre «a» then pull the ball-joint upwards.
Ball-joints alone can be changed by removing the unlocking key with the aid of two
thin screwdrivers, unclip at «b».
To unlock the ball-joint, turn in the direction of the arrow «c».
