182
CLUTCH
GEARBOX
DRIVESHAFTS
BE4/5 GEARBOX CONTROLS
Engines : 6FZ - RFN - RLZ - RHY
Tools.
[1] Tool for positioning the gearbox control lever 8605-T Tool kit 9040-T
Adjustments.
Cables should be adjusted each time the gearbox, gear controls or power unit are removed.
Adjustment principles :
- Lock the gear lever in neutral position, using tool [1].
- Position the gearbox in neutral.
- Anchor the ball-joints on the gearbox levers.
- Lock the cable lengths with the ball-joint locking keys.
Inside the vehicle.
- Remove the central console (See corresponding operation).
- Remove the plastic blank at (a).
- Insert tool [1] fully and rotate a quarter turn to lock the gear control lever.
- At neutral.
B2CP3E7C
