245
Practical information
DS4_en_Chap09_info-pratiques_ed03-2015
Bulbs with lugs, type H1, H7... take care
to position them correctly to ensure the
best lighting.
Model with directional xenon and
full-LED headlamps
1. Daytime running lamps / sidelamps
(LEDs).
2. Directional main beam / dipped beam
headlamps (D1S).
3. Direction indicators (LEDs).
4. Directional foglamps (LEDs).
Model with halogen headlamps
(type 1)
1. Direction indicators (H21 clear).
2. Dipped beam headlamps (H7).
3. Main beam headlamps (H1).
4. Daytime running lamps / sidelamps
(P21/5W XL).
5. Directional front foglamps (H11).
Front lamps
Model with halogen headlamp
and LED light signature (type 2)*
1. Direction indicators (LEDs).
2. Daytime running lamps / sidelamps
(LEDs).
3. Dipped beam headlamps (H7).
4. Main beam headlamps (H7).
5. Directional front foglamps (H11).
Bulbs with lugs, type H1, H7... take care
to position them correctly to ensure the
best lighting.
* LED: light emitting diodes.
