Front seats
Manual adjustments
Forwards-backwards
F Raise the control and slide the seat
forwards or backwards.
F Release the control to lock the position.
Seat height
F Pull the control upwards to raise or push
it downwards to lower, as many times as
necessary, to obtain the position required.
Seat backrest angle
F Turn the control knob to adjust the seat
backrest angle.
As a safety measure, seat adjustments should only be done when stationary.
Before moving the seat backwards, ensure that there is nothing that might prevent the full travel of the seat, so as to avoid the risk of of jamming
the seat caused by the presence of objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement immediately.
