CITROEN DS 4 - Page 309

307
Technical data
DS4_en_Chap11_caracteristiques_ed03-2015
Petrol engine THP 160 THP 165 S&S THP 200 THP 210 S&S
Gearbox
Automatic
(6-speed)
EAT6 automatic
(6-speed)
Manual
(6-speed)
Manual
(6-speed)
Model code:
NX...
5FMA
5GZT/S
5GZT/1S
5FU8
5FU8/1
5GMM/S
Cubic capacity (cc) 1 598 1 598 1 598 1 598
Bore x stroke (mm) 77 x 85.8 77 x 85.8 77 x 85.8 77 x 85.8
Max power*: EU standard (kW) 120 121 147 155
Max power engine speed (rpm) 6 000 6 000 5 500 6 000
Max torque: EU standard (Nm) 240 240 275 285
Max torque engine speed (rpm) 1 400 1 400 1 700 1 750
Fuel Unleaded Unleaded Unleaded Unleaded
Catalytic converter Yes Yes Yes Yes
Engine oil capacity (in litres)
(with filter replacement)
4.25 4.25 4.25 4.25
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation
(Directive 1999/99/EC).
