CITROEN DS 4 - Page 313

311
Technical data
DS4_en_Chap11_caracteristiques_ed03-2015
Diesel engine BlueHDi 150 S&S BlueHDi 180 S&S
Gearbox
Manual
(6-speed)
EAT6 automatic
(6-speed)
Model code:
NX...
AHRM/S
AHRM/1S
AHRM/2S
AHWT/S
AHWT/1S
AHWT/2S
Cubic capacity (cc) 1 997 1 997
Bore x stroke (mm) 85 x 88 85 x 88
Max power*: EU standard (kW) 110 132
Max power engine speed (rpm) 4 000 3 750
Max torque: EU standard (Nm) 370 400
Max torque engine speed (rpm) 2 000 2 000
Fuel Diesel Diesel
Catalytic converter Yes Yes
Particle filter (FAP) Yes Yes
Engine oil capacity (in litres)
(with filter replacement)
6.1 5.1
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation
(Directive 1999/99/EC).
.../S: model fitted with Stop & Start.
.../1: model fitted with low rolling resistance tyres.
.../2: model fitted with very low rolling resistance tyres.
