JUMPY-ATLANTE-VP_EN_CHAP01_PRISE EN MAIN_ED01-2014
Opening the bonnet
123
Diesel engines Petrol engine
124
153
Towing eye
122
Partially open the bonnet, lift the safety
catch and raise the bonnet.
Secure the stay in one of the two notches,
according to the height required, to hold the
bonnet open.
Lift the cover at the foot of the left-hand
seat and pull the release lever upwards.
At the front, unclip the cover by pressing it
at the bottom.
At the rear, unclip the cover using a coin or
the flat part of the towing eye.
Take care when working under the bonnet.
Refer to "Levels" in section 6 for advice on use of the fluids.
