- Unclip the battery compartment cover.
- Remove the red battery terminal (+).
When you have finished, close the cover
carefully.
Fuses A (amps) Allocation
1 30 Heated seats
2 20 Row 3 12V socket
3 40/50 Trailer fusebox (accessory)
4 - Free
36 15 Hinged door locks
37 10 Hinged door locks
38 20 Hinged door rear wiper
39 10 Rear ventilation
40 5 Folding mirrors
