11
○○○○○○○○○
Refrigerated air dryer GX8200 Series
Manufacturer's Liability
Illegal modications or repairs using nonstandard parts
by user.
WARNING
Design & Selection
AppIications
Use for applications other than dehumidifying compressed
air is prohibited.
This product must not be used for medical devices
for caisson shields or breathing devices.
CAUTION
Do not mount and use this device onto transportation
equipment such as vehicles or ships.
In case of using the air dryer in the compressed air
line with rapid compressor fluctuation, be sure to
install the air tank after the air dryer so that the
pressure uctuation becomes 0.34MPa/min or less.
If the pressure uctuation is rapid, it may result in
malfunction.
S
udden burden changes may results in dew point’s
specification value changes. Hence, in case that
dew point efficiency must be strictly controlled,
please select model that has exibility on ability.
CAUTION
QuaIity of air
Do not use this product if inlet air contains corrosive
gases, chemicals, organic solvents, or combustible
gases.
CAUTION
Air temperature
Do not use air that exceeds the maximum inlet
temperature.
If the inlet temperature is high, install an after cooler,
etc., and lower air to the maximum inlet temperature
(or less). Drainage generated in the after cooler
must be removed before the dryer.
Refer to the example of system selection for details
on the model no. of filter used on the secondary
side of the product.
Transportation
This product is lled with less than 12kg of refrigerant
(R-134a, R-410A). Always follow respective laws and
ordinances when transporting this product (by land,
sea or air).
WARNING
WARNING
Main line component
Safety precautions
Always read this section before starting use.
Refer to Pneumatic, Vacuum and Auxiliary Components No.CB-024SA for general
precautions.
The manufacturer cannot be held liable in the following
cases:
Serious errors in use occur due to the operator.
To Next Page
