Fitting the battery. In order to operate, Oasis® requires a new 9V (6LR61) Alkaline battery, with an expiry date exceeding one year.
To insert or replace the battery, proceed as follows: Act on the keys on the sides of the front panel (1) until you hear it engage. SIf
present, remove the at battery (2). Connect the new battery to the connector respecting the polarity (3). Put the new battery into
the battery compartment (4). Replace the front panel (5). For optimal operation, it is recommended that the battery is replaced at
least once a year. In any case, before using Oasis®, check the battery charge by turning the programming selector switch to any
programme and checking the led light: the led ashes approximately every 2 seconds the battery is charged, the led stays o the
battery is drained and needs to be replaced.
Connection. In order to ensure that Oasis® operates correctly, the two lengths of hose leading from the tank panel must be
long enough to touch the oor before they are connected to the drippers in the rst pots: this simple precaution is necessary
to make sure that watering starts correctly.
Unroll the hose moving around the plants making sure that they do not obstruct people or animals and select the shortest
possible path. Insert the hose into the forks of the individual stakes until it takes on the correct shape, taking care not to
create kinks in the hose. Once all the pots have been connected, bring the hose back to the second connector in the front
panel of Oasis® (if necessary, cut o the excess hose using scissors).
