F i l o x S e r i e s F i l t e r
Installation Operation Maintenance Manual
FILOX WS ISS 1 \page 24
FILOX Series Filters CF1865 to CF 3072
Model CF1865 CF2160 CF2469 CF3072
Valve WS1.5 WS2 WS2 WS2
Filter Vessel 1865 2162 2472 3072
Parameter Unit
Height of
Filter
Mm 1722 1721 1915 2202
Diameter of
Filter
Mm 458 534 610 762
Height of
Valve
mm 170 340 340 340
Filter Inlet
Conn.
Inches
BSPM
1.5 2 2 2
Filter Outlet
Conn.
Inches
BSPM
1.5 2 2 2
Drain Conn. Inches
BSPM
1 2 2 2
Qty. of
Gravel
Bags 2 3 5 8
Qty of Filox Bags 10 12 16 22
Electrical
Power
Watts 1.2 1.2 1.2 1.2
PRESSURE 1.7 Bar MAXIMUM OPERATING TEMPERATURE 45.0C
HEADROOM - Allow 100 mm greater than overall height.
