6
English
1. Turn the remote control unit over, then slide
the rear cover in the direction of the arrow.
2. Insert the AA (UM-3/1.5V) batteries that
came with the remote control unit facing in
the directions shown in the figure, then close
the rear cover.
Notes:
Using batteries improperly can cause them to explode.
Take note of the following points:
When replacing batteries, replace both batteries with
new ones.
Do not short-circuit, disassemble or heat batteries.
Do not dispose of batteries into fire or flames.
Dispose of spent batteries properly.
6. REMOTE CONTROL
1 2 3 4 5 6
Receiver for remote control unit
Signal transmitter
Operating range: 30° in all directions
¡
£
¢
§
ª
º
Remote control unit
Inserting the Batteries
Rear side
AA (UM-3/1.5V)
Batteries
Rear cover
If you buy the RCB-130-200, sold separately, you can enjoy the use of the remote control function.
