22 039-1949-20 DRIVE PWB 1
(WITHOUT COMPONENT)
23 039-1950-20 LOADING PWB 1
(WITHOUT COMPONENT)
24 060-0252-01 PHOTO-TR 1
25 620-0999-21 LS-SPRING 1
26 620-1575-21 SWITCH PLATE 1
27 620-1007-22 CLAMP PLATE M 1
28 620-1008-24 CLAMP PLATE R 1
29 620-1009-21 CLAMPER PLATE 1
30 620-1016-20 GAP PLATE R 1
31 620-1017-20 GAP PLATE F 1
32 620-1018-20 MG EJECT PLATE 1
33 620-1019-20 SLIDE PLATE R 1
34 620-1020-20 SLIDE PLATE F 1
35 620-1031-21 LOADING ARM 1
36 620-1034-23 SIDE PANEL 1
37 621-0587-21 SCREW HOLD BASE 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
38 801-4912-60 VINYL-COAT-WIRE(BRN) 1
39 621-0589-20 SECOND GEAR 1
40 621-0590-20 LS GEAR 1
41 621-0591-20 PICK UP GUIDE 1
42 621-0592-21 LS-HOLDER 1
43 621-0593-20 LS GUIDE 1
44 802-4906-60 VINYL-COAT-WIRE(RED) 1
45 621-0597-20 V-GEAR A 1
46 621-0630-22 HOLDER-G-RAIL R 1
47 621-0631-21 HOLDER-G-RAIL L 1
48 621-0703-20 L-GEAR A 1
49 621-0633-20 L-GEAR B 1
50 805-4912-60 VINYL-COAT-WIRE(GRN) 1
51 621-0635-20 V-HELICAL GEAR 1
52 621-0636-21 CLAMPER RING 1
53 624-3022-00 LEAD SCREW 1
54 629-0061-00 GEAR DAMPER 1
