Clarion DCZ625 Service Manual

DCZ625
DCZ628
- 8 -
55 716-0484-00 SCREW(M2×2.5) 23
56 716-0675-00 SCREW(M2×5.5) 1
57 716-1716-00 SCREW(M2×3) 10
58 716-3469-00 SCREW 2
59 735-2006-11 D-SEMS-SCREW(M2×6) 1
60 739-1722-17 SCREW(M1.7×2.2) 2
61 739-2022-17 SCREW(M2×2.2) 2
62 743-1500-10 E-RING 3
63 743-2000-10 E-RING 2
64 745-0789-01 DRIVE WASHER 1
65 746-0761-00 WASHER 7
66 750-3461-21 DISC-H-SPRING 1
67 750-3462-20 GAP SPRING 2
68 750-3463-20 MG LOCK SPRING 1
69 750-3464-20 MG EJECT SPRING 1
70 750-3492-22 CLAMPER SPRING 1
71 800-4906-60 VINYL-COAT-WIRE(BLK) 1
72 SMA-188-100 MOTOR ASSY(LOADING) 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
■ELECTRICAL PARTS LIST
Main PWB(B1) section
C1 178-1052-78 16V1uF
C2 043-0533-50 0.047uF
C3 042-0426-31 6.3V100uF
C4 183-1073-17 6.3V100uF
C5 046-6822-58 6800pF
C6 178-1052-78 16V1uF
C7 168-1042-78 16V0.1uF
C8 183-3363-27 10V33uF
C9 183-3363-27 10V33uF
C10 168-1042-78 16V0.1uF
C11 168-1042-78 16V0.1uF
C12 045-5096-50 5pF
C13 183-3363-27 10V33uF
C14 178-1052-78 16V1uF
C16 168-1032-55 0.01uF
C17 045-5601-50 56pF
C18 045-1011-50 100pF
C19 168-1032-55 0.01uF
C20 043-0533-50 0.047uF
C21 046-1532-78 0.015uF
C22 045-4701-50 47pF
C23 043-0533-50 0.047uF
C24 046-1522-58 1500pF
C25 046-4722-58 4700pF
C26 046-1032-78 0.01uF
C27 043-0533-50 0.047uF
C28 046-3332-78 0.033uF
C29 046-3332-78 0.033uF
C30 046-4712-58 470pF
C31 045-4701-50 47pF
C33 043-0533-50 0.047uF
C34 043-0533-50 0.047uF
C36 042-0452-81 10V220uF
C37 168-1042-78 16V0.1uF
C38 168-1042-78 16V0.1uF
C39 166-1801-50 18pF
C40 166-1801-50 18pF
C41 168-1032-55 0.01uF
C42 168-1042-78 16V0.1uF
C43 183-3363-27 10V33uF
C44 168-1032-55 0.01uF
C45 168-1032-55 0.01uF
C47 166-1011-50 100pF
C48 183-3363-27 10V33uF
C49 183-1063-37 16V10uF
C50 183-1063-37 16V10uF
C51 042-0576-00 5.5V0.1F
C52 183-1063-37 16V10uF
C53 183-1063-37 16V10uF
C54 183-1063-37 16V10uF
C55 043-0533-50 0.047uF
C56 046-1032-78 0.01uF
C58 046-1032-78 0.01uF
C59 183-1063-37 16V10uF
C60 045-6801-50 68pF
C61 045-6801-50 68pF
C62 183-1073-17 6.3V100uF
C64 046-1032-78 0.01uF
C65 045-2201-50 22pF
C66 045-2201-50 22pF
C67 183-2263-37 16V22uF
C69 183-2263-37 16V22uF
C70 184-4773-31 16V470uF
C71 046-1032-78 0.01uF
C74 183-1073-17 6.3V100uF
C75 183-2263-37 16V22uF
C76 183-2263-37 16V22uF
C77 183-2263-37 16V22uF
C78 183-2263-37 16V22uF
C79 183-2263-37 16V22uF
C80 183-2263-37 16V22uF
C81 178-3342-78 0.33uF
D1 001-0516-90 MA111
D2 001-1305-90 DAN217U
D3 001-1304-90 DAN202U
D4 001-0466-90 S5688B
D5 001-0466-90 S5688B
D6 001-0516-90 MA111
D7 001-0504-35 HZS6C2L
D8 001-0516-90 MA111
IC1 051-5710-90 TA2157F
IC2 051-6060-08 BD7961FM
IC3 051-5806-00 GP1S94
IC4 051-3289-00 BA09ST
IC5 051-6376-00 TC94A14FA
IC6 051-6600-38 CA0008AM
IC7 052-5046-01 M30621M8A-F27GP
IC8 051-5407-08 S-80721AN
IC9 051-0350-93 NJM4558M
IC10 051-5434-08 S-80843ALNP-EA7
IC11 051-0350-93 NJM4558M
IC12 051-7232-08 74VHC4066M
J1 074-1138-65 15P
J2 074-1158-56 6P
J3 074-1158-58 8P
J4 074-1158-64 14P
L1 010-3050-93 10uH
L2 010-2285-57 BLM21B102
L3 010-2285-57 BLM21B102
L4 010-2285-57 BLM21B102
L5 010-2285-57 BLM21B102
Q1 191-1237-50 2SB1237
Q2 191-1237-50 2SB1237
Q3 191-1237-50 2SB1237
Q4 193-1306-00 2SD1306
Q5 193-1306-00 2SD1306
Q6 125-2004-92 RN1402
Q7 190-1048-50 2SA1048
Q8 125-2004-92 RN1402
Q9 125-0014-92 DTA114
Q10 190-1162-00 2SA1162
Q11 193-1858-50 2SD1858
Q12 125-2004-92 RN1402
R1 033-1041-15 1/16W 100kΩ
R2 033-1041-15 1/16W 100kΩ
R3 033-1041-15 1/16W 100kΩ
R4 033-1041-15 1/16W 100kΩ
R5 033-1041-15 1/16W 100kΩ
R6 033-1041-15 1/16W 100kΩ
R7 033-2211-15 1/16W 220Ω
R8 111-2711-98 1/16W 270Ω
R9 033-6831-15 1/16W 68kΩ
R10 111-2201-98 1/4WS 22Ω
R11 111-2201-98 1/4WS 22Ω
R12 119-1031-15 1/16W 10kΩ
R13 119-2231-15 1/16W 22kΩ
R14 033-8211-15 1/16W 820Ω
R15 111-1001-98 1/4WS 10Ω
R16 119-1031-15 1/16W 10kΩ
R17 119-1531-15 1/16W 15kΩ
R18 033-6831-15 1/16W 68kΩ
R19 033-2721-15 1/16W 2.7kΩ
R20 033-1011-15 1/16W 100Ω
R21 033-1021-15 1/16W 1kΩ
R22 033-1031-15 1/16W 10kΩ
R23 033-1831-15 1/16W 18kΩ
R24 033-1531-15 1/16W 15kΩ
R25 033-1031-15 1/16W 10kΩ
R26 033-4731-15 1/16W 47kΩ
R27 033-1041-15 1/16W 100kΩ
R28 033-5621-15 1/16W 5.6kΩ
R29 033-1041-15 1/16W 100kΩ
R31 111-2711-98 1/16W 270Ω
R32 033-1041-15 1/16W 100kΩ
R33 033-3331-15 1/16W 33kΩ
R34 033-1051-15 1/16W 1MΩ
R35 033-4711-15 1/16W 470Ω
R36 119-2211-15 1/16W 220Ω
R37 033-3321-15 1/16W 3.3kΩ
R38 119-4731-15 1/16W 47kΩ
R39 033-4731-15 1/16W 47kΩ
R40 033-1041-15 1/16W 100kΩ
R41 033-4731-15 1/16W 47kΩ
R42 033-4731-15 1/16W 47kΩ
R43 033-1011-15 1/16W 100Ω
R44 033-1011-15 1/16W 100Ω
R45 033-1031-15 1/16W 10kΩ
R46 033-1031-15 1/16W 10kΩ
R47 033-5621-15 1/16W 5.6kΩ
R48 033-1031-15 1/16W 10kΩ
R49 033-4731-15 1/16W 47kΩ
R50 033-4711-15 1/16W 470Ω
R51 033-1041-15 1/16W 100kΩ
R52 119-1041-15 1/16W 100kΩ
R53 033-1531-15 1/16W 15kΩ
R54 033-1531-15 1/16W 15kΩ
R55 033-2231-15 1/16W 22kΩ
R56 033-1021-15 1/16W 1kΩ
