Clarion DCZ625 Service Manual

DCZ625
DCZ628
- 9 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R57 033-4731-15 1/16W 47kΩ
R58 033-2731-15 1/16W 27kΩ
R59 033-2731-15 1/16W 27kΩ
R60 033-1031-15 1/16W 10kΩ
R61 033-1031-15 1/16W 10kΩ
R62 033-1031-15 1/16W 10kΩ
R63 033-1031-15 1/16W 10kΩ
R64 033-1021-15 1/16W 1kΩ
R65 033-1531-15 1/16W 15kΩ
R66 033-4731-15 1/16W 47kΩ
R67 033-1031-15 1/16W 10kΩ
R68 033-1031-15 1/16W 10kΩ
R69 033-8221-15 1/16W 8.2kΩ
R70 119-1041-15 1/16W 100kΩ
R71 119-1041-15 1/16W 100kΩ
R72 119-1041-15 1/16W 100kΩ
R73 119-1041-15 1/16W 100kΩ
R74 033-1031-15 1/16W 10kΩ
R75 119-1011-15 1/16W 100Ω
R76 119-1011-15 1/16W 100Ω
R77 119-1011-15 1/16W 100Ω
R78 119-1011-15 1/16W 100Ω
R79 033-4721-15 1/16W 4.7kΩ
R80 033-2211-15 1/16W 220Ω
S1 013-7404-50 00110676
S2 013-6100-10 SKHLLD
S3 013-7404-50 00110676
T1 009-0679-00 E1-19
X1 061-3038-00 16.9344MHz
X2 060-1505-50 CSTCC10MG
Connector PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
J301 074-1194-00 13P
P301 075-0305-00 DIGITAL OUT
S301 013-3968-00 SSSS2
Loading PWB(B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D501 001-0563-00 GL380
Q501 060-0252-01 PT4850F
S501 013-7413-50 SPVG12
S502 013-7413-50 SPVG12
Drive PWB(B4) section
REF No. PART No. DESCRIPTION
S503 013-7413-50 SPVG12
