Clarion DPX1001.2 Service Manual

PARTS LIST for DPX1001.2 EXPLODED VIEW
NO PARTNO QTY DESCRIPTION SPEC Unit
1 77-00253-00 1 HEATSINK 381mm PCS
1 77-00254-00 2 SUB HEATSINK 381mm PCS
2 YH-00007-00 2 SCREW PCB A+B+C+D KIT
3 76-00224-01 3 FUSE ATC-30A
(
UL
)
PCS
4 32-00657-00 1 TERMINAL
(
4-PIN
)
] KTU-9214A PCS
4 32-00658-00 1 TERMINAL
(
3-PIN
)
] KTU-9217A PCS
5 78-00300-00 1 KAPTON 25mm*45mm PCS
5 78-00301-00 1 KAPTON 25mm*95mm PCS
6 74-00153-00 14 CLIP BLACK PCS
7 78-00302-00 2 INSULATOR 0.085 #4180 PCS
8 74-00158-00 2 CLIP- BIG BLACK PCS
9 72-00312-01 1 Bottom Panel 379.5mm PCS
10 ST-RP230-08 6 SCREW for Bottom Panel RP Head, Ni 3*8 PCS
11 SM-RP430-20 4 Screw for Fan Bi
g
Pan Head3*20 Black PCS
11 NM-OH330-01 4 BOLT for FAN M3.0*P0.5+W PCS
12 75-00001-00 1 FAN D6015B12M 150mm+2P
(
XH
)
PCS
13 ST-IH230-08 11 Screw for Rear Panel Ni 3*8 PCS
13 ST-IH230-12 1 Screw for Rear Panel Hexa-Internal,Ni3*12 PCS
14 71-00457-00 1 Rear Panel DPX1001.2 PCS
15 71-00456-00 1 Front Panel DPX1001.2 PCS
10-00546-00 1 PCB with Parts
(
Main
)
DPX1001.2 KIT
11-00546-00 1 P.C.B. w/o Parts DPX1001.2 PCS
11-22098-00 1 P.C.B. w/o Parts BC2 PCS
73-00108-03 2 MESH 381mm PCS
75-00005-01 2 NAMEPLATE BC2 CLARION PCS
75-00008-00 1 LOGO CLARION PCS
75-00009-00 1 NAMEPLATE SET PCS
78-00308-00 6 MICA 25*20mm PCS
79-D1001-GK 1 GIFT BOX DPX1001.2 PCS
80-D1001-GK 1 I/B DPX1001.2 PCS
SM-RP430-05 1 SCREW M/R 3*5 PCS
