Clarion DPX1001.2 Service Manual

DPX1001.2 rev: 1.02 BO
M
Qty Reference Part Name Manufacturer Description
1U2 7805 Motorola 7805 5V 1A pos. regulator
1U1 7812 Motorola 7812 12V 1A pos. regulator
6 D11 D13 D15-18 1N4148 1N4148 Diode Axial DO-35 50mA 100V
4 D9-10 D12 D14 1N4934 General Instrument 1N4934 Diode DO-41 Fast Recovery 1A 100V
1 DZ3 1N5232B 1N752A or 1N5232B 5.6V ZENER
1 DZ1 1N5233B 1N5233B 6V ZENER
1 DZ6 1N966A 1N966A or 1N5246B 16V ZENER
1 DZ2 1N967A 1N967B or 1N5248B 18V ZENER
2 DZ4-5 1N975A 1N975A or 1N5259B 39V ZENER
4 Q1 Q3-5 2N6715 Central Semi 2N6715 NPN 2A 50V TO-237
2 Q6-7 2N6726 Central Semi 2N6726 PNP 2A 50V TO-237
2 L6-7 BEAD Panasonic EXC-ELSA39 FERRITE BEAD 110 OHM @ 100MHz
29 C13-14 C30-31 C42 C47-49 C55 C62 C64 C68-70 C80-81 CAP-.1U-CER-MONO Panasonic ECU-S1H104KBB CAP mono ceramic .1U 50V 5mm LS
C84-85 C88 C95-96 C99 C102-103 C108 C110-111 C114-115
13 C7-8 C11-12 C15-17 C19 C41 C45 C57 C63 C82 CAP-.1U-MMYL Panasonic ECQ-V1H104JL CAP MMYL .1U 50V 5% 5mm LS
2 C9 C20 CAP-.22U-100V-MMYL Panasonic - ECQ-V1224JM CAP MMYL .22U 100V 5% 7.5mm LS
4 C79 C91 C101 C106 CAP-.22U-MMYL Panasonic ECQ-V1H224JL CAP MMYL .22U 50V 5% 5mm LS
7 C52 C60 C89-90 C104-105 C117 CAP-.47U-MMYL Panasonic ECQ-V1H474JL CAP MMYL .47U 50V 5% 5mm LS
2 C10 C21 CAP-.68U-100V-MMYL Panasonic - ECQ-E1684KF CAP MMYL .68U 100V 10% 10mm LS
12 C27-28 C34-35 C44 C46 C50-51 C56 C58 C66-67 CAP-1000U-50 Panasonic ECA-1HFQ102 1000U 50V RAD105C LOW ESR 16Dx25Hx7.5LS
1C3 CAP-100U-25 Panasonic NHG ECA-1EHG101 100U 25V 20% RAD 105C 6.3Dx11Hx2.5LS
2 C5 C71 CAP-100U-25 Panasonic ECA-1EHG101 100U 25V 20% RAD 105C 6.3Dx11Hx2.5LS
1 C76 CAP-10P-CER Panasonic ECC-F1H100D CAP CERAMIC DISC 10P 50V 2.5 LS
4 C78 C83 C93 C109 CAP-10U-50 Panasonic ECA-1HFG100 CAP RAD 105C 5Dx11Hx2LS 10UF 50V
2 C40 C61 CAP-150P-MMYL Panasonic ECQ-B1H151KF CAP MMYL 150P 50V 5mm LS
2 C86-87 CAP-18P-CER Panasonic ECC-F1H180J CAP CERAMIC DISC 18P 50V 2.5 LS
7 C1-2 C18 C22-23 C112 C116 CAP-1N-MMYL Panasonic ECQ-B1H102JF CAP MMYL 1N 50V 5% 5mm LS
4 C33 C59 C65 C113 CAP-1U-50 Panasonic ECA-1HHG010 CAP ALECT 1U 50V 20% 5Dx11Hx2LS
6 C38-39 C53-54 C72-73 CAP-3300U-25 Panasonic ECA-1EFQ332 3300U 25V rad low ESR .023R 105C 20% 18dx31.5hx7.5mmLS
4 C74-75 C100 C107 CAP-33P-CER-2.5LS Panasonic ECC-F1H330J Ceramic Disc Cap 33P 100V 2.5mm LS
2 C97-98 CAP-39N-MMYL Panasonic ECQ-B1H393JF CAP MMYL 33N 50V 5% 5mm LS
2 C4 C6 CAP-470U-50 Panasonic EEU-FC1H471 470U 50V RAD105C LOW ESR 12.5Dx25Hx5LS
2 C24 C29 CAP-47P-CER-500V PANASONIC ECC-D2H470K5 CAP MMYL 47P 500V 5% 5mm LS
2 C92 C94 CAP-47U-25 Panasonic ECE-A1EFG470 47U 25V 20% RAD 105C 6.3Dx11Hx2.5 LS
1 C77 CAP-4U7-50 Panasonic ECA-1HHG4R7 CAP ALECT 4.7U 50V RAD 105C 5Dx11Hx2LS
4 C25 C32 C36-37 CAP-56N-MMYL Panasonic ECQ-B1H563JF CAP MMYL 56N 50V 5% 5mm LS
2 C26 C43 CAP.47U-250V-COMBO Thompson PK474J2L .47UF 250V FILM CAP LS 17.5 19.5 22.5 COMBO
2 L1 L4 CHOKE-5.8UH-AIR Drawing no: DPX1000-8 Inductor air core 5.8uH 44 turns 20 ga. .2 ID
2 L3 L5 CHOKE-9UH Drawing no: DPX1000-7 Inductor Micro-Metal T106-2 core 9uH
2 L8-9 CHOKE100UH J.W. MILLER 78F101J Inductor 100uH
1 L2 CHOKE_1000_TRIPATH Drawing no DPX1000-5 Inductor Micro-Metal T157-52 core 1KW
1J9 CONN_2P_2.5MM Fairland JS-1135-2 2.5mm 2 pos header stright
1 J3 CON\KTU-9214A-1X4 KYUNG DONG KTU-9214A CONN BARRIER 1x4 AU RT ANGLE
1 J6 CON\KTU-9217A-1X3 KYUNG DONG KTU-9217A Conn Barrier large power 1x3 rt angle
