DXZ645MP 21
English
Different pieces of music heard by plural listeners (2-ZONE function)
Adjusting the sound level for the
MAIN zone
You can adjust the sound level only for the MAIN
zone. To adjust the sound level for the SUB zone,
adjust it in the headphone (WH104/WH204) side.
Tu r ning the [ROTARY] knob to adjust the sound
level for the MAIN zone.
Counterchanging the sources of the
MAIN and SUB zones
You can supersede the music sources of the MAIN
and SUB zones.
Press and hold the [ISR] button for 1 second or
longer to counterchange the sources of the MAIN
and SUB zones.
“REVERSE” is displayed for 2 seconds on the dis-
play.
Switching sources
1. Press the [ ] button to select the control
zone (“MAIN” or “SUB”).
Every time the button is pressed, the “MAIN
ZONE” changes to the “SUB ZONE” or vice
versa.
“MAIN” or “SUB” on the display lights at that
time, thereby indicating that the relevant
zone becomes ready to operate.
2. Press the [FNC] button to select a source in
the control zone.
Every time the button is pressed, the follow-
ings appear in turn.
● For a source group included in this unit:
Radio ➜ CD/MP3 ➜ AUX ➜ Radio...
● For a source group in external equip-
ment:
AUX ➜ CD changer ➜ DVD changer ➜ TV
➜ AUX...
∗ The name of equipment that is not connected
to this unit is not displayed.
•To change a current musical performance etc., press
the button that controls the selected source ([SCN]
button, etc.).
Oparation
2-ZONE
turned off
2-ZONE
turned on
2-ZONE
turned off
Source
change
2-ZONE
turned on
MAIN zone
Radio playback
Radio playback
Radio playback
External
equipment (CD
changer)
External
equipment (CD
changer)
SUB zone
Radio playback
AUX
Radio playback
External
equipment (CD
changer)
Radio playback
● Example for source change
+DXZ645MP-009-ENG 11/6/03, 3:59 AM21

Clarion DXZ645MP Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	9 dBf
50dB quieting sensitivity	15 dBf
alternate channel selectivity	70 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

CD Player

system	Compact disc digital audio system
usable discs	Compact disc
frequency response (±1 dB)	5 Hz to 20 kHz
signal to noise ratio (1 kHz)	100 dB
dynamic range (1 kHz)	95 dB
harmonic distortion	0.01%

Audio

maximum power output	208 W (52 W ✕ 4 ch)
continuous average power output	17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
bass control action (50 Hz/80 Hz/120 Hz)	+16 dB, -12dB
treble control action (8 kHz/12 kHz)	±12 dB
line output level (CD 1 kHz)	1.8 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
current consumption	Less than 15 A, 3A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	2.86 lb. (1.3 kg)
weight / remote control unit	1 oz. (30 g) (including battery)
dimensions / source unit	7" (Width) ✕ 2" (Height) ✕ 6-3/16" (Depth)
dimensions / remote control unit	1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 1-1/8" (Depth)
