Clarion DXZ745MP Service Manual

-10-
DXZ745MP/DXZ746MP
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 377 163-1063-35 16V 10uF C 910 166-1011-50 100pF D 223 001-1310-00 KDS160
C 378 163-2253-65 50V 2.2uF C 912 168-1022-55 1000pF D 224 001-0466-91 S5688G
C 379 163-2253-65 50V 2.2uF C 913 168-4722-55 4700pF D 225 001-0466-91 S5688G
C 380 163-2253-65 50V 2.2uF D 101 001-2403-90 MIF60 D 227 001-1310-00 KDS160
C 381 163-1063-35 16V 10uF D 102 001-2403-90 MIF60 D 229 001-0466-90 S5688B
C 382 178-1052-78 1uF D 103 001-2403-90 MIF60 D 230 001-0466-90 S5688B
C 383 163-1063-35 16V 10uF D 104 001-2403-90 MIF60 D 231 001-0466-90 S5688B
C 384 163-1063-35 16V 10uF D 105 001-2403-90 MIF60 D 241 001-0504-45 HZS9B1L
C 385 178-1052-78 1uF D 106 001-2403-90 MIF60 D 242 001-0504-50 HZS11A2L
C 386 163-3353-65 50V 3.3uF D 107 001-2403-90 MIF60 D 280 001-2606-90 MIFS4
C 387 178-3342-78 0.33uF D 108 001-2403-90 MIF60 D 301 001-0529-34 MA8062L
C 388 178-1052-78 1uF D 201 001-0592-00 RM4Z D 401 001-1310-00 KDS160
C 389 163-3363-25 10V 33uF D 203 001-0504-46 HZS9B2L D 402 001-1310-00 KDS160
C 390 168-1042-78 0.1uF D 211 001-1310-00 KDS160 D 403 001-0529-44 MA8082M
C 391 168-1042-78 0.1uF D 212 001-1310-00 KDS160 D 404 001-1310-00 KDS160
C 392 168-1042-78 0.1uF D 213 001-1310-00 KDS160 D 405 001-1310-00 KDS160
C 394 163-1063-35 16V 10uF D 214 001-0466-91 S5688G D 406 001-1310-00 KDS160
C 395 163-2253-65 50V 2.2uF D 221 001-0466-90 S5688B D 603 001-1310-00 KDS160
C 396 163-2253-65 50V 2.2uF IC 1 051-6201-90
LC72146M
D 610 001-1310-00 KDS160
C 397 168-2222-55 2200pF IC 101 051-2053-00 LA47508 D 651 001-7062-90 CL150FG
C 398 168-2222-55 2200pF IC 220 051-3201-90 AN77L06 F 101 060-8023-58 CHIP FUSE
C 399 163-2253-65
50V 2.2uF
IC 230 051-1014-08 TA7291F FIL 301 060-3110-90 CHIP FUSE
C 401 042-1669-00 16V 100uF IC 280 051-3605-90 NJM2360A L 403 010-3105-62 EMI COIL
C 402 166-1011-50 100pF IC 301 051-5020-90 M61508FP L 404 010-3105-62 EMI COIL
C 430 163-1063-35
16V 10uF
IC 302 051-3034-90 NJM4558V L 405 010-3105-62 EMI COIL
C 439 168-2222-55
2200pF
IC 304 051-6702-08 LC89052T L 601 010-3107-50 2.2uH
C 440 168-2222-55
2200pF
IC 305 051-6703-08 AK4384 L 602 010-3107-50 2.2uH
C 441 168-2222-55
2200pF
IC 306 051-5030-90
M61523FP
L 603 010-3107-50 2.2uH
C 442 168-2222-55 2200pF IC 308 051-5835-90
SHAKIT
L 604 010-3107-50 2.2uH
C 443 168-2222-55 2200pF IC 309 051-3263-90
NJU7200U3
P 500 074-1106-12 12P
C 444 168-2222-55 2200pF IC 401 051-5834-90
uPD5701-028
P 501 074-1106-12 12P
C 445 168-1042-78 0.1uF IC 406 051-3034-90 NJM4558V Q 6 125-3004-90 KTA1504S
C 446 168-1042-78 0.1uF IC 602 051-6600-58
HA12187FP
Q 7 125-3004-90 KTA1504S
C 447 168-1042-78 0.1uF IC 604 052-3934-00
M30622MWP-128GP
Q 8 125-2199-93 KRC103S
C 448 168-1042-78 0.1uF IC 605 051-5437-08
S-80821ANMP
Q 201 102-3420-00 2SC3420
C 449 168-1042-78 0.1uF IC 606 051-0869-55
NJM2103M
Q 202 108-0241-50 2SK241
C 450 163-2273-25 10V 220uF J 2 074-1138-70 20P Q 210 125-3007-90 KTA1298
C 451 163-1073-15 6.3V 100uF J 201 074-1214-00 16P Q 211 125-2199-96 KRC106S
C 456 163-1063-35 16V 10uF J 601 074-1194-00 13P Q 212 125-3004-90 KTA1504S
C 457 163-1063-35 16V 10uF J 602 074-1198-68 18P Q 213 192-2712-00 2SC2712
C 605 042-1505-80 25V 1uF J 604 076-0313-02 2P Q 214 125-3007-90 KTA1298
C 606 168-4732-78 0.047uF L 1 010-2275-53 220uH Q 222 125-3004-90 KTA1504S
C 613 042-0576-00 5.5V 0.1F L 2 010-2285-56 BLM21B222S Q 223 125-2199-93 KRC103S
C 614 168-1032-55 0.01uF L 3 010-2285-56 BLM21B222S Q 224 101-0941-00 2SB941
C 615 042-1577-00 6.3V 100uF L 52 010-4046-00 30uF Q 225 125-3004-90 KTA1504S
C 616 163-1063-35 16V 10uF L 101 010-8026-00 CHOKE Q 226 192-2712-00 2SC2712
C 617 168-1022-55 1000pF L 202 010-3406-54 2.2uH Q 227 125-4014-90 KTC2020D
C 619 168-4732-78 0.047uF L 211 010-3407-59 5.6uH Q 228 125-2199-93 KRC103S
C 620 178-2242-78 0.22uF L 280 010-3406-66 22uH Q 229 190-1416-00 2SA1416
C 630 166-1011-50 100pF L 281 010-3406-66 22uH Q 230 125-3007-90 KTA1298
C 631 166-1011-50 100pF L 282 010-6003-03 270uH Q 231 190-1416-00 2SA1416
C 632 168-1032-55 0.01uF L 283 010-2285-56 BLM21B222S Q 232 125-0199-92 KRA102S
C 633 168-1032-55 0.01uF L 301 010-2285-58
BLM21A102FPB
Q 233 125-2199-93 KRC103S
C 635 166-1011-50
100pF
L 302 010-2285-58
BLM21A102FPB
Q 235 125-2199-93 KRC103S
C 636 166-1011-50 100pF L 303 010-2285-58
BLM21A102FPB
Q 236 125-3004-90 KTA1504S
C 637 166-1011-50 100pF L 304 010-2285-58
BLM21A102FPB
Q 240 125-2199-93 KRC103S
C 638 166-1011-50 100pF L 305 010-2285-58
BLM21A102FPB
Q 242 125-2199-93 KRC103S
C 640 166-1011-50 100pF L 308 010-2285-58
BLM21A102FPB
Q 244 125-0199-92 KRA102S
C 641 166-1011-50 100pF L 309 010-2285-58
BLM21A102FPB
Q 245 125-2199-96 KRC106S
C 642 166-1011-50 100pF L 310 010-2285-58
BLM21A102FPB
Q 248 125-2199-93 KRC103S
C 643 166-1011-50 100pF L 311 010-2285-58 BLM21A102FPB Q 250 125-4015-90 KTC2026
C 645 166-1011-50 100pF L 312 010-2285-58 BLM21A102FPB Q 251 125-2199-93 KRC103S
C 691 163-2263-15 6.3V 22uF L 313 010-2285-58 BLM21A102FPB Q 252 125-2199-96 KRC106S
C 692 163-2263-15 6.3V 22uF L 314 010-2285-58 BLM21A102FPB Q 301 125-2199-93 KRC103S
C 693 166-1007-50 10pF L 321 010-3406-66 22uH Q 401 125-0199-92 KRA102S
C 694 166-1007-50 10pF L 322 010-3406-66 22uH Q 414 125-2199-96 KRC106S
C 695 166-4711-50 470pF L 331 010-3105-62 EMI COIL Q 415 192-2712-00 2SC2712
C 696 166-4711-50 470pF L 332 010-3105-62 EMI COIL Q 416 125-0199-96 KRA106S
C 904 168-1032-55 0.01uF L 401 010-3406-66 22uH Q 424 125-2199-96 KRC106S
C 905 168-1032-55 0.01uF L 402 010-3105-62 EMI COIL Q 425 125-2199-96 KRC106S
C 907 168-1032-55 0.01uF D 222 001-0466-90 S5688B Q 426 125-0199-96 KRA106S
