Clarion DXZ745MP Service Manual

-9-
pin113: Memo Data 6 :I/O: Parallel data input/output for Memory IC.
pin114: Memo Data 7 :I/O: Parallel data input/output for Memory IC.
pin115: Memo Data 8 :I/O: Parallel data input/output for Memory IC.
pin116: Memo Data 9 :I/O: Parallel data input/output for Memory IC.
pin117: Memo Data 10 :I/O: Parallel data input/output for Memory IC.
pin118: Memo Data 11 :I/O: Parallel data input/output for Memory IC.
pin119: Memo Data 12 :I/O: Parallel data input/output for Memory IC.
pin120: CN VCC : IN : Connect to VCC.
pin121: Memo Data 13 :I/O: Parallel data input/output for Memory IC.
pin122: Memo Data 14 :I/O: Parallel data input/output for Memory IC.
pin123: Memo Data 15 :I/O: Parallel data input/output for Memory IC.
pin124: SRQ : O : V BUS SRQ output.
pin125: VDD : - : Positive supply voltage.
pin126: VSS : - : Negative supply voltage.
pin127: NU :IN: Not in use.
pin128: VSS : - : Negative supply voltage.
pin129: NU :IN: Not in use.
pin130: VDD : - : Positive supply voltage.
pin131: Memo Addrss 0: O : Address output to Memory IC.
pin132: Memo Addrss 1: O : Address output to Memory IC.
pin133: Memo Addrss 2: O : Address output to Memory IC.
pin134: Memo Addrss 3: O : Address output to Memory IC.
pin135: SYS POWER : O : System power supply control signal output.
pin136: Memo Addrss 4: O : Address output to Memory IC.
pin137: Memo Addrss 5: O : Address output to Memory IC.
pin138: Memo Addrss 6: O : Address output to Memory IC.
pin139: Memo Addrss 7: O : Address output to Memory IC.
pin140: Memo Addrss 8: O : Address output to Memory IC.
pin141: Memo Addrss 9: O : Address output to Memory IC.
pin142: VDD : - : Positive supply voltage.
pin143: Memo Addrss 21:O : Control signal output for Memory IC.
pin144: VSS : - : Negative supply voltage.
051-5441-08 BD4828G-TR Precision Vlotage Detector 2.8V
Terminal description
pin 1: OUTPUT : N channel open drain output, positive logic.
pin 2: VDD : Positive supply voltage.
pin 3: GND : Ground.
pin 4: NC : Not in use.
pin 5: NC : Not in use.
1
2
3
5
4
N.C.
N.C.
OUTPUT
VDD
GND
ELECTRICAL PARTS LIST
Main PWB (B1) section
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT 1
092-4000-51 ANT-RECEPT C 125 166-4711-50 470pF C 313 163-1063-35 16V 10uF
BL 1 880-2090B TUNER C 126 166-4711-50 470pF C 314 168-4732-78 0.047uF
C 1 168-2232-55 0.022uF C 127 166-4711-50 470pF C 315 168-4732-78 0.047uF
C 4 163-1053-65 50V 1uF C 128 166-4711-50 470pF C 316 163-2253-65 50V 2.2uF
C 5 168-2732-55 0.027uF C 129 166-4711-50 470pF C 317 163-2253-65 50V 2.2uF
C 6 168-2732-55 0.027uF C 130 166-4711-50 470pF C 318 168-3322-55 3300pF
C 7 188-4763-37 16V 47uF C 131 166-4711-50 470pF C 320 163-1063-35 16V 10uF
C 8 168-2232-55 0.022uF C 132 166-4711-50 470pF C 321 163-2253-65 50V 2.2uF
C 9 168-2232-55 0.022uF C 134 166-2211-50 220pF C 322 163-2253-65 50V 2.2uF
C 10 168-6822-55 6800pF C 135 166-2211-50 220pF C 323 168-3322-55 3300pF
C 11 042-1631-50 10V 100uF C 136 166-2211-50 220pF C 324 163-1063-35 16V 10uF
C 12 042-1631-50 10V 100uF C 137 166-2211-50 220pF C 325 168-1022-55 1000pF
C 16 168-1042-78 0.1uF C 201 042-1545-00 16V 2200uF C 326 168-6832-78 0.068uF
C 18 163-1053-65 50V 1uF C 202 172-2231-15 0.022uF C 327 168-6832-78 0.068uF
C 20 163-4763-15 6.3V 47uF C 203 042-1669-00 16V 100uF C 328 168-1042-78 0.1uF
C 22 166-1011-50 100pF C 204 188-2263-37 16V 22uF C 329 168-1022-55 1000pF
C 23 166-1011-50 100pF C 205 168-4732-78 0.047uF C 330 168-1022-55 1000pF
C 24 166-3311-50 330pF C 210 163-2263-15 6.3V 22uF C 332 163-1063-35 16V 10uF
C 25 166-1501-50 15pF CH C 211 163-2263-35 16V 22uF C 333 163-1063-35 16V 10uF
C 26 166-1501-50 15pF CH C 216 187-1073-35 16V 100uF C 334 163-1063-35 16V 10uF
C 28 168-1532-55 0.015uF C 222 188-4763-37 16V 47uF C 335 163-1063-35 16V 10uF
C 29 168-2232-55 0.022uF C 223 168-2232-55 0.022uF C 337 163-2253-65 50V 2.2uF
C 55 166-2201-50 22pF CH C 224 172-4731-15 0.047uF C 338 163-2253-65 50V 2.2uF
C 66 166-2201-50 22pF CH C 230 042-1631-50 10V 100uF C 340 163-2263-15 6.3V 22uF
C 67 168-1032-55 0.01uF C 241 188-1063-37 16V 10uF C 351 168-1042-78 0.1uF
C 68 168-2232-55 0.022uF C 243 042-1631-50 10V 100uF C 353 042-0398-53 16V 3.3uF TAN
C 101 178-2242-78 0.22uF C 245 168-1042-78 0.1uF C 354 168-1042-78 0.1uF
C 102 178-2242-78 0.22uF C 279 188-1073-27 10V 100uF C 356 168-1042-78 0.1uF
C 103 178-2242-78 0.22uF C 280 042-0416-60 25V 10uF TAN C 357 042-0423-97 16V 10uF TAN
C 104 178-2242-78 0.22uF C 281 042-1452-81 10V 220uF C 358 042-0423-97 16V 10uF TAN
C 106 042-0560-84 16V 47uF C 282 042-1631-50 10V 100uF C 359 168-1042-78 0.1uF
C 107 042-0560-56 50V 3.3uF C 283 042-1631-50 10V 100uF C 360 042-0397-50 16V 1uF TAN
C 108 042-0560-63 16V 22uF C 284 168-2232-55 0.022uF C 362 168-1042-78 0.1uF
C 109 043-0506-50 0.1uF C 285 168-1042-78 0.1uF C 363 166-1011-50 100pF
C 110 043-0506-50 0.1uF C 286 166-2211-50 220pF C 364 166-1011-50 100pF
C 111 043-0506-50 0.1uF C 287 168-1042-78 0.1uF C 366 168-1022-55 1000pF
C 112 043-0506-50 0.1uF C 302 163-1063-35 16V 10uF C 367 168-4732-78 0.047uF
C 113 043-0506-50 0.1uF C 303 168-1032-55 0.01uF C 368 168-6822-55 6800pF
C 114 043-0506-50 0.1uF C 304 168-1032-55 0.01uF C 370 168-2222-55 2200pF
C 115 043-0506-50 0.1uF C 306 163-1063-35 16V 10uF C 371 168-2222-55 2200pF
C 116 043-0506-50 0.1uF C 307 168-3922-55 3900pF C 372 168-2222-55 2200pF
C 121 163-1063-35 16V 10uF C 308 168-3922-55 3900pF C 373 168-2222-55 2200pF
C 122 163-1063-35 16V 10uF C 310 163-1063-35 16V 10uF C 374 163-2253-65 50V 2.2uF
C 123 163-1063-35 16V 10uF C 311 163-1063-35 16V 10uF C 375 163-2253-65 50V 2.2uF
C 124 163-1063-35 16V 10uF C 312 163-1063-35 16V 10uF C 376 168-1042-78 0.1uF
DXZ745MP/DXZ746MP
