Clarion DXZ745MP Service Manual

-12-
DXZ745MP/DXZ746MP
REF No.
PART No.
DESCRIPTION
REF No.
PART No.
DESCRIPTION
REF No.
PART No.
DESCRIPTION
R 692
119-0000-05
R 699
119-2231-15
1/16W 22Kohm
SUP 51
060-0122-91
DSP-141N-S00B
R 694
119-0000-05
R 905
119-0000-05
X 1
061-9013-00
7.2MHZ
R 695
119-1031-15
1/16W 10Kohm
R 907
119-6821-15
1/16W 6.8Kohm
X 601
060-1505-50
10MHZ
R 696
119-2231-15
1/16W 22Kohm
S 601
013-6100-00
SWITCH
PWB
039-2460-00
MAIN(WITHOUT
R 697
119-3311-15
1/16W 330ohm
S 602
013-7106-00
TKR00120670MM
COMPONENT)
R 698
119-3311-15
1/16W 330ohm
S 603
013-7206-50
SPPB530701
JW
JW JW
Sub PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 500 042-0397-54 10V 2.2uF P 501 076-0659-12 12P R 530 119-1231-15 1/16W 12Kohm
C 505 042-0397-54 10V 2.2uF Q 501 193-1306-00 2SD1306 R 531 119-2231-15 1/16W 22Kohm
C 507 042-0397-54 10V 2.2uF Q 502 193-1306-00 2SD1306 R 532 119-2231-15 1/16W 22Kohm
C 508 042-0397-54 10V 2.2uF Q 503 193-1306-00 2SD1306 R 533 119-2231-15 1/16W 22Kohm
C 509 042-0416-56 10V 22uF Q 504 193-1306-00 2SD1306 R 534 119-2231-15 1/16W 22Kohm
C 510 042-0416-56 10V 22uF Q 505 193-1306-00 2SD1306 R 535 119-2231-15 1/16W 22Kohm
C 511 042-0416-56 10V 22uF Q 506 193-1306-00 2SD1306 R 536 119-2231-15 1/16W 22Kohm
C 512 042-0416-56 10V 22uF R 511 119-1231-15 1/16W 12Kohm R 537 119-3311-15 1/16W 330ohm
C 513 042-0416-56 10V 22uF R 512 119-1231-15 1/16W 12Kohm R 538 119-3311-15 1/16W 330ohm
C 515 042-0416-56 10V 22uF R 513 119-1031-15 1/16W 10Kohm R 539 119-3311-15 1/16W 330ohm
C 530 042-0397-54 10V 2.2uF R 514 119-1031-15 1/16W 10Kohm R 540 119-3311-15 1/16W 330ohm
C 533 166-2201-50 22pF R 519 119-1041-15 1/16W 100Kohm R 541 119-3311-15 1/16W 330ohm
C 534 166-2201-50 22pF R 520 119-1041-15 1/16W 100Kohm R 542 119-3311-15 1/16W 330ohm
C 535 166-2201-50 22pF R 521 119-1041-15 1/16W 100Kohm R 543 119-1021-15 1/16W 1Kohm
C 536 166-2201-50 22pF R 522 119-1041-15 1/16W 100Kohm R 544 119-1021-15 1/16W 1Kohm
C 537 166-2201-50 22pF R 523 119-1231-15 1/16W 12Kohm R 545 119-1021-15 1/16W 1Kohm
C 538 166-2201-50 22pF R 524 119-1031-15 1/16W 10Kohm R 587 119-1041-15 1/16W 100Kohm
C 541 042-0397-54 10V 2.2uF R 525 119-1031-15 1/16W 10Kohm R 588 119-1041-15 1/16W 100Kohm
IC 501 051-3026-90 NJM4580V R 526 119-1231-15 1/16W 12Kohm R 596 119-1021-15 1/16W 1Kohm
IC 502 051-3026-90 NJM4580V R 527 119-1031-15 1/16W 10Kohm PWB 039-2306-00 PWB(WITHOUT
IC 503 051-3026-90 NJM4580V R 528 119-1031-15 1/16W 10Kohm COMPONENT)
P 500 076-0659-12 12P R 529 119-1231-15 1/16W 12Kohm
Switch PWB(B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C 701 168-1042-78 0.1uF Q 701 125-3004-90 KTA1504S R 737 119-2211-15 1/16W 220ohm
C 705 042-0423-97 16V 10ohm TAN Q 702 192-2712-51 2SC2712GL R 738 119-2211-15 1/16W 220ohm
C 706 168-1042-78 0.1uF Q 705 192-2712-00 TRANSISTOR R 739 119-2711-15 1/16W 270ohm
C 707 042-0423-97 16V 10ohm TAN Q 706 192-2712-00 TRANSISTOR R 740 119-2711-15 1/16W 270ohm
C 708 042-0671-00 16V 4.7ohm TAN Q 707 192-2712-00 TRANSISTOR R 741 119-1031-15 1/16W 10Kohm
C 710 168-1042-78 0.1uF Q 708 125-2199-93 KRC103S R 742 119-2221-15 1/16W 2.2Kohm
C 711 042-0671-00 16V 4.7ohm TAN Q 709 125-3007-90 KTA1298 R 743 119-1031-15 1/16W 10Kohm
C 718 168-1022-55 50V 1000pF Q 710 125-2017-96 RN1426 R 744 119-2221-15 1/16W 2.2Kohm
C 719 168-1022-55 50V 1000pF Q 711 125-2017-96 RN1426 R 748 119-1011-15 1/16W 100ohm
C 720 168-1022-55 50V 1000pF Q 712 125-2017-96 RN1426 R 749 119-1011-15 1/16W 100ohm
C 721 042-0398-53 16V 3.3ohm TAN Q 713 125-2017-96 RN1426 R 750 032-0140-00
1/10W 56Kohm (F)
C 722 042-0398-53 16V 3.3ohm TAN Q 714 125-2017-96 RN1426 R 751 032-0140-53
1/10W 2.2Kohm (F)
C 723 042-0398-53 16V 3.3ohm TAN Q 715 125-2017-96 RN1426 R 752 032-0140-73
1/10W 820ohm (F)
C 725 166-1011-50 50V 100pF Q 716 125-3007-90 KTA1298 R 753 119-4731-15 1/16W 47Kohm
C 726 166-1011-50 50V 100pF Q 717 125-2199-93 KRC103S R 754 119-4731-15 1/16W 47Kohm
C 728 042-0671-00 16V 4.7ohm TAN R 714 119-4711-15 1/16W 470ohm R 760 119-3921-15 1/16W 3.9Kohm
D 701 001-7072-91 FRGB1304B R 715 119-2711-15 1/16W 270ohm R 761 119-1041-15 1/16W 100Kohm
D 702 001-7072-91 FRGB1304B R 716 119-2711-15 1/16W 270ohm R 762 119-1011-15 1/16W 100ohm
D 703 001-7072-91 FRGB1304B R 717 119-4711-15 1/16W 470ohm R 763 119-1011-15 1/16W 100ohm
D 704 001-7072-91 FRGB1304B R 718 119-2711-15 1/16W 270ohm R 764 119-1011-15 1/16W 100ohm
D 705 001-7072-91 FRGB1304B R 719 119-2711-15 1/16W 270ohm R 771 119-1021-15 1/16W 1Kohm
D 706 001-0529-32 MA8056M R 720 119-4711-15 1/16W 470ohm R 772 119-1021-15 1/16W 1Kohm
D 709 001-0529-32 MA8056M R 721 119-2711-15 1/16W 270ohm R 773 119-1021-15 1/16W 1Kohm
D 710 001-0529-32 MA8056M R 722 119-2711-15 1/16W 270ohm R 774 119-1041-15 1/16W 100Kohm
D 711 001-0529-32 MA8056M R 723 119-2211-15 1/16W 220ohm R 775 119-1041-15 1/16W 100Kohm
D 712 001-0529-32 MA8056M R 724 119-1811-15 1/16W 180ohm R 776 119-1041-15 1/16W 100Kohm
D 713 001-0529-32 MA8056M R 725 119-1811-15 1/16W 180ohm R 780 119-3301-15 1/16W 33ohm
D 714 001-0529-32 MA8056M R 726 119-2211-15 1/16W 220ohm R 781 119-3301-15 1/16W 33ohm
D 715 001-0529-32 MA8056M R 727 119-1811-15 1/16W 180ohm R 782 119-3301-15 1/16W 33ohm
D 716 001-0529-32 MA8056M R 728 119-1811-15 1/16W 180ohm R 783 119-3301-15 1/16W 33ohm
D 717 001-0529-32 MA8056M R 729 119-3911-15 1/16W 390ohm R 784 119-0000-05
D 718 001-0529-32 MA8056M R 730 119-3911-15 1/16W 390ohm R 786 002-0315-01 680ohm
D 719 001-0529-32 MA8056M R 731 119-5111-15 1/16W 510ohm S 701 013-6507-50 ILLUMI SWITCH
IC 701 051-6057-10 ML9090-02 R 732 119-5111-15 1/16W 510ohm S 702 013-6507-50 ILLUMI SWITCH
IC 704 051-6636-18 M62334FP R 733 119-5611-15 1/16W 560ohm S 703 013-6507-50 ILLUMI SWITCH
IR 701 060-4017-90 RS-671 R 734 119-5611-15 1/16W 560ohm S 704 013-6507-50 ILLUMI SWITCH
LCD 701
379-1298-81 INDICATOR(LCD) R 735 119-2211-15 1/16W 220ohm S 705 013-6507-50 ILLUMI SWITCH
P 701 076-0647-00
DCP CONECTOR
R 736 119-2211-15 1/16W 220ohm S 706 013-6507-50 ILLUMI SWITCH
JW
