4 M202RC-RET
1. INTRODUCTION
The M202RC-RET is a waterproof remote control panel which
allows operation of the Clarion M335-RET head unit from a
remote location. Two M202RC-RET units may be used with a
single M335-RET (using an optional M101RYC adapter). The
M202RC-RET can be connected to your boat’s illumination
circuit, backlighting the panel in low-light conditions.
What is included
• Remote control panel (1)
• One mounting bracket and four 7mm hex nuts (1 set)
• Owner’s Manual / Installation Guide (1)
Note: An extension DIN cable is available separately
(P/N M101RXC)
2. CARE AND MAINTENANCE
Clean the remote control panel with a slightly damp, soft cloth
using household glass cleaner. Do not use solvents such as
benzene, thinner, or commercially available cleaners.
From time to time, inspect the connections on the rear of the
unit for corrosion and correct as needed.
