Clarion PN-3124N-A User Manual

-11-
Note) Some parts depend on each model. The model name is specified in the description.
Main PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT101 092-2210-01 ANTENNA RECEPT C315 168-1022-55 1000pF K C533 168-5632-78 16V 0.056uF
BL101 880-2091M FM/AM TUNER C316 168-1022-55 1000pF K C534 168-5632-78 16V 0.056uF
C104 168-2222-55 2200pF K C317 166-1011-50 100pF CH C535 168-5632-78 16V 0.056uF
(PN-3124N-A) C318 168-1042-78 16V 0.1uF C536 168-5632-78 16V 0.056uF
C108 166-1511-50 150pF CH C319 168-5622-55 5600pF K C537 178-1052-78 1uF
(PN-3124N-A) C320 168-5622-55 5600pF K C540 163-1063-35 16V 10uF
C108 119-0000-05 1/10W 0 ohm JW C323 168-1022-55 1000pF K C541 168-1522-55 1500pF K
(PN-3124N-B) C324 163-2273-05 4V 220uF C546 168-1042-78 16V 0.1uF
C109 166-2201-50 22pF CH C325 168-2222-55 2200pF K C547 178-1052-78 1uF
C110 168-1042-78 16V 0.1uF C326 166-4711-50 470pF CH C549 163-2273-25 10V 220uF
C111 178-3342-78 0.33uF C327 163-2263-35 16V 22uF C550 178-4742-78 0.47uF
C112 163-4763-15 6.3V 47uF C328 168-1022-55 1000pF K C551 168-1042-38 50V 0.1uF
C113 178-1052-78 1uF C329 166-1007-50 10pF CH C552 163-4763-35 16V 47uF
C114 178-1052-78 1uF C330 163-1063-35 16V 10uF C553 163-4763-35 16V 47uF
C115 119-0000-05 1/10W 0 ohm JW C331 166-1011-50 100pF CH C554 189-3383-31 16V 3300uF
C116 168-1222-55 1200pF K C333 168-1042-78 16V 0.1uF C556 172-1041-15 0.1uF
C117 178-1052-78 1uF C334 163-4763-15 6.3V 47uF C557 163-4763-35 16V 47uF
C118 168-4732-78 0.047uF K C335 178-1052-78 1uF C559 168-6822-55 6800pF K
C119 168-1022-55 1000pF K C336 168-3332-78 0.033uF K C560 168-6822-55 6800pF K
C120 168-4722-55 4700pF K C338 168-1022-55 1000pF K C561 168-6822-55 6800pF K
C121 168-4722-55 4700pF K C339 168-1022-55 1000pF K C562 168-6822-55 6800pF K
C122 163-1073-35 16V 100uF C340 166-1007-50 10pF CH C563 168-6822-55 6800pF K
C123 168-2222-55 2200pF K C341 168-4712-55 470pF K C564 166-2201-50 22pF CH
C124 168-1022-55 1000pF K C342 168-1042-78 16V 0.1uF C565 168-6822-55 6800pF K
C125 168-2232-55 0.022uF K C343 168-1022-55 1000pF K C566 168-6822-55 6800pF K
C126 168-2232-55 0.022uF K C345 168-3322-55 3300pF K C567 043-0604-90 25V 10uF B
C127 168-1022-55 1000pF K C346 168-3322-55 3300pF K C568 168-6822-55 6800pF K
C128 168-1022-55 1000pF K C347 168-3322-55 3300pF K C569 168-6822-55 6800pF K
C129 178-1052-78 1uF C348 168-3322-55 3300pF K C571 043-0566-90 50V 2.2uF K
C130 168-1022-55 1000pF K C350 042-0643-58 6.3V 330uF C572 178-1052-78 1uF
C131 163-1073-35 16V 100uF C351 168-4722-55 4700pF K C573 168-1042-78 16V 0.1uF
C132 166-2201-50 22pF CH C352 168-2222-55 2200pF K C574 163-1063-35 16V 10uF
C133 166-2201-50 22pF CH C353 168-2222-55 2200pF K C575 168-2232-55 0.022uF K
C134 166-2201-50 22pF CH C354 168-2222-55 2200pF K C576 163-1073-35 16V 100uF
C135 166-2201-50 22pF CH C355 168-2222-55 2200pF K C577 168-2212-55 220pF K
C136 178-1052-78 1uF C356 163-1073-15 6.3V 100uF C578 119-0000-05 1/10W 0 ohm JW
C137 178-1052-78 1uF C359 168-1022-55 1000pF K CCT401 050-0145-52 1/16W 1k ohm x4
C138 178-3342-78 0.33uF C360 166-4711-50 470pF CH CCT402 050-0145-52 1/16W 1k ohm x4
C140 163-1063-35 16V 10uF C361 043-0554-90 25V 10uF CCT403 050-0145-52 1/16W 1k ohm x4
C141 163-1063-35 16V 10uF C401 168-1042-78 16V 0.1uF CCT402 050-0145-52 1/16W 1k ohm x4
(PN-3124N-A) C402 168-1042-78 16V 0.1uF D106 001-0580-90 1SS352
C142 168-1042-78 16V 0.1uF C404 166-5096-50 5pF CH D108 001-0529-48 MA8091-H
C143 166-6801-50 68pF CH C406 166-5096-50 5pF CH D109 001-0580-90 1SS352
C144 043-0548-50 2.2uF C407 168-1042-78 16V 0.1uF (PN-3124N-A)
C201 043-0548-50 2.2uF C408 163-4763-15 6.3V 47uF D208 001-0580-90 1SS352
C202 043-0548-50 2.2uF C409 168-1042-78 16V 0.1uF D210 001-0529-72 MA8200-M
C203 043-0548-50 2.2uF C412 168-1032-55 0.01uF K D211 001-9210-50 AVR-
C204 043-0548-50 2.2uF C413 163-1073-35 16V 100uF M1608C270MTAAD
C220 163-3373-15 6.3V 330uF C501 168-1042-78 16V 0.1uF D212 001-9210-50 AVR-
C227 042-0643-58 6.3V 330uF C502 168-1042-78 16V 0.1uF M1608C270MTAAD
C228 163-2273-25 10V 220uF C503 168-1042-78 16V 0.1uF D213 001-9210-50 AVR-
C229 163-1063-35 16V 10uF C504 168-1042-78 16V 0.1uF M1608C270MTAAD
C230 168-1042-78 16V 0.1uF C505 166-5611-50 560pF CH D214 001-9210-50 AVR-
C232 163-1063-35 16V 10uF C506 166-5611-50 560pF CH M1608C270MTAAD
C233 168-1042-78 16V 0.1uF C507 166-5611-50 560pF CH D215 001-2412-90 RR264M-400
C236 178-1052-78 1uF C508 166-5611-50 560pF CH D505 001-0529-48 MA8091-H
C238 178-3342-78 0.33uF C509 166-2201-50 22pF CH D506 001-2640-90 D1FJ4
C241 168-1022-55 1000pF K C510 166-2201-50 22pF CH D508 001-0529-48 MA8091-H
C242 168-1022-55 1000pF K C511 043-0554-90 25V 10uF D510 001-2015-00 RL253
C301 163-4753-65 50V 4.7uF C512 178-3342-78 0.33uF D511 001-0580-90 1SS352
C302 168-1042-78 16V 0.1uF C513 166-2201-50 22pF CH D512 001-0529-48 MA8091-H
C303 166-1811-50 180pF CH C514 166-2201-50 22pF CH D514 001-0580-90 1SS352
C304 166-1007-50 10pF CH C516 166-5611-50 560pF CH D515 001-0529-34 MA8062-L
C306 168-1042-78 16V 0.1uF C517 166-5611-50 560pF CH D516 001-0580-90 1SS352
C307 168-1042-78 16V 0.1uF C519 166-5611-50 560pF CH D567 001-0580-90 1SS352
C308 166-8097-50 8pF C CH C520 166-5611-50 560pF CH D568 001-0580-90 1SS352
C309 166-8097-50 8pF C CH C521 168-1042-78 16V 0.1uF D569 001-4301-68 HZU18B1
C310 168-1022-55 1000pF K C522 178-3342-78 0.33uF D570 001-4301-68 HZU18B1
C311 163-4753-65 50V 4.7uF C523 163-1063-35 16V 10uF D571 001-4301-68 HZU18B1
C312 168-1042-78 16V 0.1uF C525 163-1073-35 16V 100uF IC101 051-6524-90 AK2301A-E1
C313 163-4753-65 50V 4.7uF C530 163-1073-35 16V 100uF IC103 051-3034-90 NJM4558V
C314 168-1042-78 16V 0.1uF C532 168-1042-78 16V 0.1uF IC104 051-3519-90 NJU7771F05-TE2
PN-3124N
